harina [27]
3 years ago
9

What the velocity from the graph given above?

Physics
1 answer:
igomit [66]3 years ago
5 0

Answer:

i think its 4 or 35

Explanation:

its in the middle of 40 and 30

You might be interested in
3.27 moles of an ideal gas in a 50.0 L tank has a pressure of 171000 Pa. What is the temperature of the gas? (Unit=degrees C)
laiz [17]

The temperature of the gas is 41.3 °C.

Answer:

The temperature of the gas is 41.3 °C.

Explanation:

So on combining the Boyle's and Charles law, we get the ideal law of gas that is PV=nRT. Here P is the pressure, V is the volume, n is the number of moles, R is gas constant and T is the temperature. The SI unit of pressure is atm. So we need to convert 1 Pa to 1 atm, that is 1 Pa = 9.86923×10^{-6} atm. Thus, 171000 Pa = 1.6876 atm.

We know that the gas constant R = 0.0821 atmLMol–¹K-¹. Then the volume of the gas is given as 50 L and moles are given as 3.27 moles.

Then substituting all the values in ideal gas equation ,we get

1.6876×50=3.27×0.0821×T

Temperature = \frac{84.38}{0.268467} =314.3 K

So the temperature is obtained to be 314.3 K. As 0°C = 273 K,

Then 314.3 K = 314.3-273 °C=41.3 °C.

Thus, the temperature is 41.3 °C.

3 0
4 years ago
Calculate the angular velocity of the neptune (orbital period of 165 earth period) in its orbit around the sun.
ludmilkaskok [199]
The correct answer is: Angular velocity =  1.208 * 10^{-9} rad/s

Explanation:
The angular velocity is given as:
ω = \frac{2\pi}{T} --- (1)

Where T = 165 * (365 days) * (24 hours/day) * (60 minutes/hour) * (60 seconds/minute) = 5203440000 s

Plug in the value in (1):
ω = \frac{2\pi}{5203440000} = 1.208 * 10^{-9} rad/s
7 0
3 years ago
An object travels in a circular path of radius 5.0 meters at a uniform speed of 10. m/s. What is the magnitude of the object's a
vladimir1956 [14]
I think F= mv²/r
And F=ma
So, ma = mv²/r
a = v²/r
a = 100/5
a = 20 m/s
8 0
3 years ago
Read 2 more answers
Two rigid rods are oriented parallel to each other and to the ground. The rods carry the same current in the same direction. The
Galina-37 [17]

Answer:

220 A

Explanation:

The magnetic force on the floating rod due to the rod held close to the ground is F = BI₁L where B = magnetic field due to rod held close the ground = μ₀I₂/2πd where μ₀ = permeability of free space = 4π × 10⁻⁷ H/m, I₂ = current in rod close to ground and d = distance between both rods = 11 mm = 0.011 m. Also, I₁ = current in floating rod and L = length of rod = 1.1 m.

So, F = BI₁L

F = (μ₀I₂/2πd)I₁L

F = μ₀I₁I₂L/2πd

Given that the current in the rods are the same, I₁ = I₂ = I

So,

F = μ₀I²L/2πd

Now, the magnetic force on the floating rod equals its weight , W = mg where m = mass of rod = 0.10kg and g = acceleration due to gravity = 9.8 m/s²

So, F = W

μ₀I²L/2πd = mg

making I subject of the formula, we have

I² = 2πdmg/μ₀L

I = √(2πdmg/μ₀L)

substituting the values of the variables into the equation, we have

I = √(2π × 0.011 m × 0.1 kg × 9.8 m/s²/[4π × 10⁻⁷ H/m × 1.1 m])

I = √(0.01078 kgm²/s²/[2 × 10⁻⁷ H/m × 1.1 m])

I = √(0.01078 kgm²/s²/[2.2 × 10⁻⁷ H])

I = √(0.0049 × 10⁷kgm²/s²H)

I = √(0.049 × 10⁶kgm²/s²H)

I = 0.22 × 10³ A

I = 220 A

7 0
3 years ago
A steel wire of length 31.0 m and a copper wire of length 17.0 m, both with 1.00-mm diameters, are connected end to end and stre
Brut [27]

Answer:

The time taken is  t =  0.356 \ s

Explanation:

From the question we are told that

  The length of steel the wire is  l_1  = 31.0 \ m

   The  length of the  copper wire is  l_2  = 17.0 \ m

    The  diameter of the wire is  d =  1.00 \ m  =  1.0 *10^{-3} \ m

     The  tension is  T  =  122 \ N



The time taken by the transverse wave to travel the length of the two wire is mathematically represented as

              t  =  t_s  +  t_c

Where  t_s is the time taken to transverse the steel wire which is mathematically represented as

         t_s  = l_1 *  [ \sqrt{ \frac{\rho * \pi *  d^2 }{ 4 *  T} } ]

here  \rho_s is the density of steel with a value  \rho_s  =  8920 \ kg/m^3

   So

      t_s  = 31 *  [ \sqrt{ \frac{8920 * 3.142*  (1*10^{-3})^2 }{ 4 *  122} } ]

      t_s  = 0.235 \ s

 And

        t_c is the time taken to transverse the copper wire which is mathematically represented as

      t_c  = l_2 *  [ \sqrt{ \frac{\rho_c * \pi *  d^2 }{ 4 *  T} } ]

here  \rho_c is the density of steel with a value  \rho_s  =  7860 \ kg/m^3

 So

      t_c  = 17 *  [ \sqrt{ \frac{7860 * 3.142*  (1*10^{-3})^2 }{ 4 *  122} } ]

      t_c  =0.121

So

   t  = t_c  + t_s

    t =  0.121 + 0.235

    t =  0.356 \ s

4 0
3 years ago
