Answer:
Option c) are perpendicular to the electric field
Explanation:
Equipotential surfaces are perpendicular to the electric field. the electric field lines are projected outwards from the equipotential surface, i.e., the lines of the electric field are at 90
to the equipotential surface.
Equipotential surface are those surfaces that have the same potential at any point on the surface. Thus the potential difference at any point on the surface is zero due to same potential.
Any charge particle on this surface will move in a perpendicular direction to the Coulombian force. No work is done by the force on a particle moving on an equipotential surface.
C and D are units of length or distance.
A is a measured angle.
B is a unit of angular measurement.
Answer:
<em>The force of friction acting on the block has a magnitude of 15 N and acts opposite to the applied force.</em>
Explanation:
<u>Net Force
</u>
The Second Newton's law states that an object acquires acceleration when an unbalanced net force is applied to it.
The acceleration is proportional to the net force and inversely proportional to the mass of the object.
If the object has zero net force, it won't get accelerated and its velocity will remain constant.
The m=2 kg block is being pulled across a horizontal surface by a force of F=15 N and we are told the block moves at a constant velocity. This means the acceleration is zero and therefore the net force is also zero.
Since there is an external force applied to the box, it must have been balanced by the force of friction, thus the force of friction has the same magnitude acting opposite to the applied force.
The force of friction acting on the block has a magnitude of 15 N opposite to the applied force.
Answer:
The number of turns, N = 1750
Explanation:
It is given that,
The inner radius of a toroid, r = 12 cm
Outer radius, r' = 15 cm
The magnetic field at points within the coils 14 cm from its center is,
R = 14 cm = 0.14 m
Current, I = 1.5 A
The formula for the magnetic field at some distance from its center is given by :



N = 1750
So, the number of turns must have in a toroidal solenoid is 1750. Hence, this is the required solution.
