All categories

3 years ago

I

Physics

1 answer:

Alika [10]3 years ago

6 0

Answer:

1.The main advantage of an electromagnet over a permanent magnet is that the magnetic field can be quickly changed by controlling the amount of electric current in the winding. However, unlike a permanent magnet that needs no power, an electromagnet requires a continuous supply of current to maintain the magnetic field.

You might be interested in

You drop a 0.375 kg ball from a height of 1.37 m. It hits the ground and bounces up again to a height of 0.67 m. How much energy

Radda [10]

2.57 joule energy lose in the bounce .

Explanation:

when ball is the height of 1.37 m from the ground it has some gravitational potential energy with respect to hits the ground

Formula for gravitational potential energy given by

Potential Energy = mgh

Where ,

m = mass

g = acceleration due to gravity

h = height

Potential energy when ball hits the ground

m= 0.375 kg

h = 1.37 m

g = 9.8 m/s²

$Potential Energy = 0.375\times9.8\times1.37$

Potential Energy = 5.03 joule

Potential energy when ball bounces up again

h= 0.67 m

$Potential Energy = 0.375\times0.67\times9.8$

Potential Energy = 2.46 joule

Energy loss = 5.03 - 2.46 = 2.57 joule

2.57 joule energy lose in the bounce

6 0

3 years ago

Spring compressed 10cm by 100N force and held in place with Pin. Pin is pulled and block is pushed Up the incline. Uk(coefficien

otez555 [7]

The compression of 10 cm by a 100 N force on the plane that has a

coefficient of friction of 0.39 give the following values.

The velocity of the block after the Spring extends 7 cm is approximately 1.73 m/s

The height at which the block stops rising is approximately 1.1415 m

The length of the incline is approximately 1.536 m

<h3>How can the velocity and height of the block be calculated?</h3>

Mass of the block, m = 3 kg

$Spring \ constant, K = \dfrac{100 \, N}{0.1 \, m} = \mathbf{ 1000\, N/m}$

Coefficient of kinetic friction, $\mu_k$ = 0.39

Therefore, we have;

Friction force = $\mathbf{\mu_k}$ ·m·g·cos(θ)

Which gives;

Friction force = 0.39 × 3 × 9.81 × cos(48°) ≈ 7.68

Work done by the motion of the block, W ≈ 7.68 × d

The work done = The kinetic energy of the block, which gives;

$\mathbf{\dfrac{1}{2} \times k \cdot x^2 }= 7.68 \cdot d$

The initial kinetic energy in the spring is found as follows;

K.E. = 0.5 × 1000 N/m × (0.1 m)² = 5 J

The initial velocity of the block is therefore;

5 = 0.5·m·v²

v₁ = √(2 × 5 ÷ 3) ≈ 1.83

Work done by the motion of the block, W ≈ 7.68 N × 0.07 m ≈ 0.5376 J

Chane in kinetic energy, ΔK.E. = Work done

ΔK.E. = 0.5 × 3 × (v₁² - v₂²)

Which gives;

ΔK.E. = 0.5 × 3 × (1.83² - v₂²) = 0.5376

Which gives;

The velocity of the block after the Spring extends 7 cm, v₂ ≈ 1.73 m/s

The height at which the block will stop moving, h, is given as follows;

$At \ the \ maximum \ height, \ h, \ we \ have ; \ \dfrac{1}{2} \times 1000 \times 0.1^2 = 7.68 \times x$

Which gives;

$Length \ of \ the \ incline \ at \ maximum \ height, \ x_{max} =\dfrac{ 7.68 }{ \dfrac{1}{2} \times 1000 \times 0.1^2 } \approx 1.536$

The distance up the inclined, the block rises, at maximum height is therefore;

$x_{max}$ ≈ 1.536 m

Therefore;

h = 1.536 × sin(48°) ≈ 1.1415

The height at which the block stops rising, h ≈ 1.1415 m

From the above solution for the height, the length of the incline is he

distance along the incline at maximum height which is therefore;

Length of the incline, $x_{max}$ = 1.536 m

Learn more about conservation of energy here:

brainly.com/question/7538238

5 0

2 years ago

Which type of change results in a new substance being produced?

malfutka [58]

Answer:

Chemical

Explanation:

A chemical change is also known as chemical reaction. It is a change that results to the formation of a new substance.

7 0

3 years ago

Read 2 more answers

If the weight of 1kg is 10 N in water what is the density of the stone

vekshin1

Answer:

I have a screenshot of this.

Explanation:

5 0

3 years ago

1. Have you ever tried to undergo an X- ray to test on youur body? What can you see in the fiom after the examination? Why is th

liraira [26]

Answer:

1) λ < 2d, 2) nfrared imaging technique, 3) each color there is a different index of refraction

Explanation:

We are going to answer the three questions

1) When x-rays pass through matter in order to be dispersed, their wavelength must be of the order of the length of separation in the atoms and molecules of the body, in solid bones this length is similar and they scatter and reflect the x-rays therefore they can be observed, the fat and the soft tissue have a much greater separation therefore the x-rays cannot be reflected and consequently it is not observable by this technique.

2) At airports they use the infrared imaging technique, where the image is taken for the infrared wavelength, which is the heat part of the electromagnetic spectrum; consequently, when the image is viewed, the hottest areas appear brighter and, since when a person has a virus, his temperature rises, his temperature rises, it is possible to observe people with a higher temperature.

3) when white light hits a prism it is refracted with the equation

n₁ sin θ₁ = n₂ sin θ₂

where the incidence of refraction depends on the wavelength, therefore for each color there is a different index of refraction and consequently the light is separated in its different colors.

5 0
