Answer:
y = 2.74 m
Explanation:
The linear thermal expansion processes are described by the expression
ΔL = α L ΔT
Where α the thermal dilation constant for concrete is 12 10⁻⁶ºC⁻¹, ΔL is the length variation and ΔT the temperature variation in this case 20ªc
If the bridge is 250 m long and is covered by two sections each of them must be L = 125 m, let's calculate the variation in length
ΔL = 12 10⁻⁶ 125 20
ΔL = 3.0 10⁻² m
Let's use trigonometry to find the height
The hypotenuse Lf = 125 + 0.03 = 125.03 m
Adjacent leg L₀ = 125 m
cos θ = L₀ / Lf
θ = cos⁻¹ (L₀ / Lf)
θ = cos⁻¹ (125 / 125.03)
θ = 1,255º
We calculate the height
tan 1,255 = y / x
y = x tan 1,255
y = 125 tan 1,255
y = 2.74 m
Answer:
μsmín = 0.1
Explanation:
- There are three external forces acting on the riders, two in the vertical direction that oppose each other, the force due to gravity (which we call weight) and the friction force.
- This friction force has a maximum value, that can be written as follows:
where μs is the coefficient of static friction, and Fn is the normal force,
perpendicular to the wall and aiming to the center of rotation.
- This force is the only force acting in the horizontal direction, but, at the same time, is the force that keeps the riders rotating, which is the centripetal force.
- This force has the following general expression:
where ω is the angular velocity of the riders, and r the distance to the
center of rotation (the radius of the circle), and m the mass of the
riders.
Since Fc is actually Fn, we can replace the right side of (2) in (1), as
follows:
- When the riders are on the verge of sliding down, this force must be equal to the weight Fg, so we can write the following equation:
- (The coefficient of static friction is the minimum possible, due to any value less than it would cause the riders to slide down)
- Cancelling the masses on both sides of (4), we get:
- Prior to solve (5) we need to convert ω from rev/min to rad/sec, as follows:
- Replacing by the givens in (5), we can solve for μsmín, as follows:
Answer:
Eyeglass lenses will almost always be convex on the outer surface, the one farthest from the eye, simply to fit it to the curvature of the face.
Explanation:
Hope this helped Mark BRAINLIEST!!!
Light. Because we all should know that light travels faster than sound so light will get there first
Answer: b. The flow of air is neither toward the warm air mass nor toward the cold air mass.
A stationary front forms between two air masses. A stationary front results when the warm front or cold front air stops moving. This occurs due to the fact that warm front and cold front air masses being opposite to each other but neither of them are able to repel the other. This affects the climatic conditions of the region. The weather is often cloudy along a stationary front and also supported with fall of rain and snow especially if the air in the front is cold with low atmospheric pressure.
<em>Therefore, along a stationary front the flow of air is neither toward the warm air mass nor toward the cold air mass.
