Can anyone please help me with this homework now!!!

When two resistors are wired in series with a 12 V battery, the current through the battery is 0.33 A. When they are wired in pa

MA_775_DIABLO [31]

Answer:

If R₂=25.78 ohm, then R₁=10.58 ohm

If R₂=10.57 then R₁=25.79 ohm

Explanation:

R₁ = Resistance of first resistor

R₂ = Resistance of second resistor

V = Voltage of battery = 12 V

I = Current = 0.33 A (series)

I = Current = 1.6 A (parallel)

In series

$\text{Equivalent resistance}=R_{eq}=R_1+R_2\\\text {From Ohm's law}\\V=IR_{eq}\\\Rightarrow R_{eq}=\frac{12}{0.33}\\\Rightarrow R_1+R_2=36.36\\ Also\ R_1=36.36-R_2$

In parallel

$\text{Equivalent resistance}=\frac{1}{R_{eq}}=\frac{1}{R_1}+\frac{1}{R_2}\\\Rightarrow {R_{eq}=\frac{R_1R_2}{R_1+R_2}$

$\text {From Ohm's law}\\V=IR_{eq}\\\Rightarrow R_{eq}=\frac{12}{1.6}\\\Rightarrow \frac{R_1R_2}{R_1+R_2}=7.5\\\Rightarrow \frac{R_1R_2}{36.36}=7.5\\\Rightarrow R_1R_2=272.72\\\Rightarrow(36.36-R_2)R_2=272.72\\\Rightarrow R_2^2-36.36R_2+272.72=0$

Solving the above quadratic equation

$\Rightarrow R_2=\frac{36.36\pm \sqrt{36.36^2-4\times 272.72}}{2}$

$\Rightarrow R_2=25.78\ or\ 10.57\\ If\ R_2=25.78\ then\ R_1=36.36-25.78=10.58\ \Omega\\ If\ R_2=10.57\ then\ R_1=36.36-10.57=25.79\Omega$

∴ If R₂=25.78 ohm, then R₁=10.58 ohm

If R₂=10.57 then R₁=25.79 ohm

6 0

3 years ago

Betty is sitting on of her surfboard out in the ocean. She is waiting for the perfect wave to come along so she can ride it in t

givi [52]

Crest is the part of the wave which does this.

A sound wave is the sample of disturbance resulting from the movement of strength visiting through a medium, including air, water or every other liquid or stable remember as it propagates far from the supply of the sound.

The sound waves are generated by a sound source, such as the vibrating diaphragm of a stereo speaker. The sound source creates vibrations in the surrounding medium. because the supply continues to vibrate the medium, the vibrations propagate far from the supply at the rate of sound, hence forming the sound wave.

A sound wave is not a transverse wave with crests and troughs, however alternatively a longitudinal wave with compressions and rarefactions.

Learn more about wave here:- brainly.com/question/1199084

#SPJ1

7 0

1 year ago

he drag characteristics of a torpedo are to be studied in a water tunnel using a 1 : 7 scale model. The tunnel operates with fre

dusya [7]

Answer:20.03 m/s

Explanation:

Given

$L_r=1:7$

velocity of Prototype $v_p=53 m/s$

Taking Froude number same for both flow as it is a dimensionless number for different flow regimes in open Flow

$(\frac{v_m}{\sqrt{L_mg}})=(\frac{v_p}{\sqrt{L_pg}})$

$v_m=v_p\times \sqrt{\frac{L_m}{L_p}}$

$v_m=53\times \frac{1}{\sqrt{7}}$

$v_m=20.03 m/s$

4 0

3 years ago

Do you believe that

LUCKY_DIMON [66]

Answer:

In my opinion, I think we do change when people come to our lives because the way we feel around people makes us feel a certain way around all people in our lives in a good way. They can change our lives by being there and helping us physically and mentally. We do have the choice to follow what someone is trying to change us. Example if we have a problem like addiction, we can choose to get help from anyone or choose not to. Traumas can affect us, but we need to seek help to not fear those problems anymore, thats why people who care about us really want us to change our way of health, addictions, and mental health. For me, as a child my dad was deported because he got a dui and decided for as punishment to be deported or to have a life sentence in the U.S. My mom suffered addiction to drugs and alcohol. I lived with my grandparents for almost my whole childhood untill the age of 9. Then my aunt got engaged and my new uncle decided to take us in because DC.S foound out that me and my other sibling weren't in school at all. Like we never attended school. So we were going to be seperated and taken for adoption untill my uncle had the heart to adopt us and here I am today. He gave us a better life because I finally experienced school,clothes, food, and a safer place to live. All the things I went through even abuse. He changed my life and we changed his. He cares about us, we helped him quit drinking, and that impacts him a lot to open up his heart and quit drinking.

Explanation:

6 0

2 years ago

Anna applies a force of 19.5 newtons to push a book placed on a table. If the normal force of the book is 51.7 newtons, what is

GarryVolchara [31]

that would be given by

[email protected]

@ representing coefficient of kinetic friction.

thus 19.5/51.7 = 0.377

6 0

3 years ago
