... The top branch of the 3-branched parallel block ... the 9 and 6 in series ...
is equivalent to a single resistor of 15 ohms.
... The 3-branched parallel block boils down to (30, 10, and 15) in parallel.
That's (1/30 + 1/10 + 1/15)⁻¹ = 5 ohms.
... The 5-ohm-equivalent block and the 20-ohm resistor form a
voltage divider across the battery.
The voltage across the 5-ohm-equivalent block is (5/25 x 30v) = 6v .
... The top branch of the block is equivalent to a (9 + 6) = 15-ohmer.
With 6v across its ends, the current through that branch is (6/15) = 0.4A .
... With 0.4A flowing through it, the 9-ohm resistor is dissipating
I²R = (0.4A)² (9 ohms) = (0.16 A²) (9 ohms) = 1.44 W (choice-3)
Answer:29 electrons
Explanation: If you look on a periodic table, the atomic number is the amount of electrons it has.
Answer:
Force, F = 77 N
Explanation:
A child in a wagon seem to fall backward when you give the wagon a sharp pull forward. It is due to Newton's third law of motion. The forward pull on wagon is called action force and the backward force is called reaction force. These two forces are equal in magnitude but they acts in opposite direction.
We need to calculate the force is needed to accelerate a sled. It can be calculated using the formula as :
F = m × a
Where
m = mass = 55 kg
a = acceleration = 1.4 m/s²

F = 77 N
So, the force needed to accelerate a sled is 77 N. Hence, this is the required solution.
<h3><u>Answer</u>;</h3>
1600 years
<h3><u>Explanation</u>;</h3>
- Half life is the time taken for a radioactive isotope to decay by half of its original amount.
- We can use the formula; N = O × (1/2)^n ; where N is the new mass, O is the original amount and n is the number of half lives.
- A sample of radium-226 takes 3200 years to decay to 1/4 of its original amount.
Therefore;
<em>1/4 = 1 × (1/2)^n</em>
<em>1/4 = (1/2)^n </em>
<em>n = 2 </em>
Thus; <em>3200 years is equivalent to 2 half lives.</em>
<em>Hence, the half life of radium-226 is 1600 years</em>
Answer:
(a) F = 320
(b) = F = -5.1625
Explanation:
The formula that converts degree Celsius (C) to degree Fahrenheit (F) is:
F = 1.8C + 32
Solving (a): F = 2C
Substitute 2C for F in the above equation
F = 1.8C + 32
2C = 1.8C + 32
Collect like terms
2C - 1.8C = 32
0.2C = 32
Multiply both sides by 5
5 * 0.2C = 32 * 5
C = 160
Recall that F = 2C
F = 2 * 160
F = 320
Solving (b): F = ¼C
Substitute ¼C for F in the above formula
F = 1.8C + 32
¼C = 1.8C + 32
Convert fraction to decimal
0.25C = 1.8C + 32
Collect like terms
0.25C - 1.8C = 32
-1.55C = 32
Divide both sides by -1.55
C = 32/(-1.55)
C = -32/1.55
C = -20.65
Recall that: F = ¼C
F = -¼ * 20.65
F = -5.1625
