Answer:
Explanation:
Given
Electric Field
velocity
mass of electron
Force on a charge Particle moving in Magnetic Field
![F=e\left [ \vec{E}+\left ( \vec{v}\times \vec{B}\right )\right ]](https://tex.z-dn.net/?f=F%3De%5Cleft%20%5B%20%5Cvec%7BE%7D%2B%5Cleft%20%28%20%5Cvec%7Bv%7D%5Ctimes%20%5Cvec%7BB%7D%5Cright%20%29%5Cright%20%5D)
![a=\frac{e\left [ \vec{E}+\left ( \vec{v}\times \vec{B}\right )\right ]}{m}](https://tex.z-dn.net/?f=a%3D%5Cfrac%7Be%5Cleft%20%5B%20%5Cvec%7BE%7D%2B%5Cleft%20%28%20%5Cvec%7Bv%7D%5Ctimes%20%5Cvec%7BB%7D%5Cright%20%29%5Cright%20%5D%7D%7Bm%7D)
![a=\frac{1.6\times 10^{-19}\left [ 2\hat{i}+5.4\hat{j}+\left ( 8\hat{i}\times 0.4\hat{k}\right )\right ]}{9.1\times 10^{-31}}](https://tex.z-dn.net/?f=a%3D%5Cfrac%7B1.6%5Ctimes%2010%5E%7B-19%7D%5Cleft%20%5B%202%5Chat%7Bi%7D%2B5.4%5Chat%7Bj%7D%2B%5Cleft%20%28%208%5Chat%7Bi%7D%5Ctimes%200.4%5Chat%7Bk%7D%5Cright%20%29%5Cright%20%5D%7D%7B9.1%5Ctimes%2010%5E%7B-31%7D%7D)
Answer:
The answer is 1250 mm
Explanation:
The path that particles move in the spectrometer is semicircular. Each of the particles has a displacement of twice the radius (2r) from the entrance to where the film is hit. According to the exercise, if the separation between the two molecules is 0.25 mm, then the difference in the radius of the molecules is equal to 0.125 mm. The ratio of mass/radius is equal for molecules, and therefore is equal to:
m = q * B * r / v
m/r = constant
(m/r)CO = (m/r)N = (28.0106 u/r) = (28.0134 u/(r + 0.000125 m))
Clearing and solving r:
r = 1.25 m = 1250 mm
