Answer:
Explanation:
- The expression for acceleration of the rolling body on an inclined plane is given as a = gsinФ/1 + k²/R²
- where Ф is the angle of inclination, R is the radius, k is the radius of gyration.
- The potential energy of the system is given as ; PE = mgh
- The potential energy will be constant for ring, cylinder, solid sphere, and hollow sphere.
- The total kinetic energy of the rolling body is ; KE = mv²/2 + Iw²/2
- Hence, the total kinetic energy of the ring, cylinder, solid sphere and hollow sphere will be constant.
2. The moment of inertia of the ring is given as ;
I = mR²
The moment of inertia of the ring is maximum and therefore reaches the bottom last.
Answer:
Explanation:
Applied force, F = 18 N
Coefficient of static friction, μs = 0.4
Coefficient of kinetic friction, μs = 0.3
θ = 27°
Let N be the normal reaction of the wall acting on the block and m be the mass of block.
Resolve the components of force F.
As the block is in the horizontal equilibrium, so
F Cos 27° = N
N = 18 Cos 27° = 16.04 N
As the block does not slide so it means that the syatic friction force acting on the block balances the downwards forces acting on the block .
The force of static friction is μs x N = 0.4 x 16.04 = 6.42 N .... (1)
The vertically downward force acting on the block is mg - F Sin 27°
= mg - 18 Sin 27° = mg - 8.172 ... (2)
Now by equating the forces from equation (1) and (2), we get
mg - 8.172 = 6.42
mg = 14.592
m x 9.8 = 14.592
m = 1.49 kg
Thus, the mass of block is 1.5 kg.
Answer with Explanation:
We are given that mass of block=0.0600 kg
Initial speed of block=0.63 m/s
Distance of block from the hole when the block is revolved=0.47 m
Final speed=3.29 m/s
Distance of block from the hole when the block is revolved=
a.We have to find the tension in the cord in the original situation when the block has speed =

Because tension is equal to centripetal force
Substitute the values

b.

c.Work don=Final K.E-Initial K.E



The correct answer is Destructive Interference.Consider the image attached below. Two waves are travelling towards each other. Blue wave always has a positive peak and the red wave always has a negative peak.
Now imagine these waves are moving through a rope. If blue waves will try to move the rope in positive direction, the red wave will pull it down, and thus the two waves will cancel the effect of each other. Thus resulting in a destructive interference.
