By working with percentages, we want to see how many inches is the center of gravity out of the limits. We will find that the CG is 1.45 inches out of limits.
<h3>What are the limits?</h3>
First, we need to find the limits.
We know that the MAC is 58 inches, and the limits are from 26% to 43% MAC.
So if 58 in is the 100%, the 26% and 43% of that are:
- 26% → (26%/100%)*58in = 0.26*58 in = 15.08 in
- 43% → (43%/100%)*58in = 0.43*58 in = 24.94 in.
But we know that the CG is found to be 45.5% MAC, then it measures:
(45.5%/100%)*58in = 0.455*58in = 26.39 in
We need to compare it with the largest limit, so we get:
26.39 in - 24.94 in = 1.45 in
This means that the CG is 1.45 inches out of limits.
If you want to learn more about percentages, you can read:
brainly.com/question/14345924
Complete Question
The complete question is shown on the first uploaded image
Answer:
a
b
New
Explanation:
From the question we are told that
The refractive index of the core is
The refractive index of the cladding is
Generally according to Snell's law
Where
is the largest angle a largest angle a ray will make with respect to the interface of the fiber and experience total internal reflection
![\theta_{max} = 90 - sin^{-1} [\frac{n_{cladding}}{n_{core}} ]](https://tex.z-dn.net/?f=%5Ctheta_%7Bmax%7D%20%3D%2090%20-%20sin%5E%7B-1%7D%20%5B%5Cfrac%7Bn_%7Bcladding%7D%7D%7Bn_%7Bcore%7D%7D%20%5D)
![\theta_{max} = 90 - sin^{-1} [\frac{1.421}{1.497}} ]](https://tex.z-dn.net/?f=%5Ctheta_%7Bmax%7D%20%3D%2090%20-%20sin%5E%7B-1%7D%20%5B%5Cfrac%7B1.421%7D%7B1.497%7D%7D%20%5D)
Given from the question the the largest angle is 5°
Generally the refraction index of the cladding is mathematically represented as
Answer:
s = 30330.7 m = 30.33 km
Explanation:
First we need to calculate the speed of sound at the given temperature. For this purpose we use the following formula:
v = v₀√[T/273 k]
where,
v = speed of sound at given temperature = ?
v₀ = speed of sound at 0°C = 331 m/s
T = Given Temperature = 10°C + 273 = 283 k
Therefore,
v = (331 m/s)√[283 k/273 k]
v = 337 m/s
Now, we use the following formula to calculate the distance traveled by sound:
s = vt
where,
s = distance traveled = ?
t = time taken = 90 s
Therefore,
s = (337 m/s)(90 s)
<u>s = 30330.7 m = 30.33 km</u>
<span>B. because they cannot make light rays converge</span>
Answer:
Its diameter increases as it flows down from the pipe. Assuming laminar flow for the water, then Bernoulli's equation can be applied.
P1-P2 + (rho)g(h1 - h2) + 1/2(rho)(v1² - v2²) = 0
Explanation:
P1 = P2 = atmospheric pressure so, P1 - P2 = 0
h1 is greater than h2 so h1-h2 is positive. Rearranging the equation above 2{ (rho)g(h1-h2) + 1/2(rho)v1²}/rho = v2²
From the continuity equation for fluids
A1v1 = A2v2
v2 = A1v1/A2
Substituting into the equation above
(A1v1/A2)² = 2{ (rho)g(h1-h2) + 1/2(rho)v1²}/rho
Making A2² the subject of the formula,
A2² = (A1v1)²× rho/(2{ (rho)g(h1-h2) + 1/2(rho)v1²}
The denominator will be greater than the numerator and as a result the diameter of the flowing stream decreases.
Thank you for reading.
