Ampres law is often written contourintegral B vector (r vector) middot dl vector = mu_0I_enclosed. The integral on the left is
1 answer:
You might be interested in
Answer:
The maximum velocity is 1.58 m/s.
Explanation:
A spring pendulum with stiffness k = 100N/m is attached to an object of mass m = 0.1kg, pulls the object out of the equilibrium position by a distance of 5cm, and then lets go of the hand for the oscillating object. Calculate the achievable vmax.
Spring constant, K = 100 N/m
mass, m = 0.1 kg
Amplitude, A = 5 cm = 0.05 m
Let the angular frequency is w.
The maximum velocity is
Answer:
a. The ratio of their resistance is 2783:64
b. The ratio of their energy is 4:23
c. The charge on the first bulb is 5.75 C
The charge on the second bulb is C
Explanation:
The voltage on one of the electric bulbs, V₁ = 40 volts
The power rating of the bulb, P₁ = 230 w
The voltage on the other electric bulbs, V₂ = 110 volts
The power rating of the bulb, P₂ = 40 w
a. The power is given by the formula, P = I·V = V²/R
Therefore, R = V²/P
For the first bulb, the resistance, R₁ = 40²/230 ≈ 6.96
The resistance of the second bulb, R₂ = 110²/40
The ratio of their resistance, R₂/R₁ = (110²/40)/(40²/230) = 2783/64
∴ The ratio of their resistance, R₂:R₁ = 2783:64
b. The energy of a bulb, E = t × P
Where;
t = The time in which the bulb is powered on
∴ The energy of the first bulb, E₁ = 230 w × t
The energy of the second bulb, E₂ = 40 w × t
The ratio of their energy, E₂/E₁ = (40 w × t)/(230 w × t) = 4/23
∴ The ratio of their energy, E₂:E₁ = 4:23
c. The charge on a bulb, 'Q', is given by the formula, Q = I × t
Where;
I = The current flowing through the bulb
From P = I·V, we get;
I = P/V
For the first bulb, the current, I = 230 w/40 V = 5.75 amperes
The charge on the first bulb per second (t = 1) is therefore;
Q₁ = 5.75 A × 1 s = 5.75 C
The charge on the first bulb, Q₁ = 5.75 C
Similarly, the charge on the second bulb, Q₂ = (40 W/110 V) × 1 s = C
The charge on the second bulb, Q₂ = C.
d. The question has left out parts
