Vanyuwa [196]
2 years ago
10

An engineering drawing shows the: (A) dimensions, tolerances, cost, and sales or use volume of a component.(B) dimensions, toler

ances, materials, and finishes of a component.(C) materials, finishes, machining operations, and dimensions of a component.(D) cost, materials, tolerances, and lead-time for a component.(E) cost, dimensions, and machining operations for a component.
Engineering
1 answer:
Leto [7]2 years ago
3 0

Answer:

(B) dimensions, tolerances, materials, and finishes of a component.

Explanation:

An engineering drawing :

  An  engineering drawing is a technical drawing which draws the actual component .

An engineering drawing shows

1. Materials

2.Dimensions

3.Tolerance

4.Finishes of a component

Engineering drawing does not shows any information about the cost of component.

So the option B is correct.

You might be interested in
Inspection with considering a variable uses gages to determine if the product is good or bad. True or False?
irina1246 [14]

Answer:A. 40% B.50% C. 60% Od 70%

Explanation:A. True B. False

4 0
2 years ago
Read 2 more answers
Water vapor at 6 MPa, 600 degrees C enters a turbine operating at steady state and expands to 10kPa. The mass flow rate is 2 kg/
kirill115 [55]

Answer:

Explanation:

Obtain the following properties at 6MPa and 600°C from the table "Superheated water".

h_1=3658.8KL/Kg\\s_1=7.1693kJ/kg.k

Obtain the following properties at 10kPa from the table "saturated water"

h_{f2}=191.81KJ/Kg.K\\h_{fg2}=2392.1KJ/Kg\\s_{f2}=0.6492KJ/Kg.K\\s_{fg2}=7.4996KJ/Kg.K

Calculate the enthalpy at exit of the turbine using the energy balance equation.

\frac{dE}{dt}=Q-W+m(h_1-h_2)

Since, the process is isentropic process Q=0

0=0-W+m(h_1-h_2)\\h_2=h_1-\frac{W}{m}\\\\h_2=3658.8-\frac{2626}{2}\\\\=2345.8kJ/kg

Use the isentropic relations:

s_1=s_{2s}\\s_1=s_{f2}+x_{2s}s_{fg2}\\7.1693=6492+x_{2s}(7.4996)\\x_{2s}=87

Calculate the enthalpy at isentropic state 2s.

h_{2s}=h_{f2}+x_{2s}.h_{fg2}\\=191.81+0.87(2392.1)\\=2272.937kJ/kg

a.)

Calculate the isentropic turbine efficiency.

\eta_{turbine}=\frac{h_1-h_2}{h_1-h_{2s}}\\\\=\frac{3658.8-2345.8}{3658.8-2272.937}=0.947=94.7%

b.)

Find the quality of the water at state 2

since h_f at 10KPa <h_2<h_g at 10KPa

Therefore, state 2 is in two-phase region.

h_2=h_{f2}+x_2(h_{fg2})\\2345.8=191.81+x_2(2392.1)\\x_2=0.9

Calculate the entropy at state 2.

s_2=s_{f2}+x_2.s_{fg2}\\=0.6492+0.9(7.4996)\\=7.398kJ/Kg.K

Calculate the rate of entropy production.

S=\frac{Q}{T}+m(s_2-s_1)

since, Q = 0

S=m(s_2-s_1)\\=2\frac{kg}{s}(7.398-7.1693)kJ/kg\\=0.4574kW/k

6 0
3 years ago
Can I get a hand? Thanks y’all much luv
Lilit [14]

Answer:

C

Explanation:

3 0
3 years ago
Water (density p-1000 is discharging from through a hole at the bottom of a graduated 71 cylinder. The mass flow rate exiting th
alexira [117]

Answer:

Please see attachment

Explanation:

Please see attachment

4 0
2 years ago
What is the magnitude of the maximum stress that exists at the tip of an internal crack having a radius of curvature of 3 × 10-4
Vladimir [108]

Answer:

maximum stress is 2872.28 MPa

Explanation:

given data

radius of curvature = 3 × 10^{-4} mm

crack length = 5.5 × 10^{-2} mm

tensile stress = 150 MPa

to find out

maximum stress

solution

we know that  maximum stress formula that is express as

\sigma m = 2 ( \sigma o ) \sqrt{\frac{a}{\delta t}}     ......................1

here σo is applied stress and a is half of internal crack and t is radius of curvature of tip of internal crack

so put here all value in equation 1 we get

\sigma m = 2 ( \sigma o) \sqrt{\frac{a}{\delta t}}

\sigma m = 2(150) \sqrt{ \frac{\frac{5.5*10^{-2}}{2}}{3*10^{-4}}}

σm = 2872.28 MPa

so maximum stress is 2872.28 MPa

8 0
2 years ago
