How do you find velocity
1 answer:
You might be interested in
Question:
A 10 gauge copper wire carries a current of 15 A. Assuming one free electron per copper atom, calculate the drift velocity of the electrons. (The cross-sectional area of a 10-gauge wire is 5.261 mm².)
Answer:
3.22 x 10⁻⁴ m/s
Explanation:
The drift velocity (v) of the electrons in a wire (copper wire in this case) carrying current (I) is given by;
v =
Where;
n = number of free electrons per cubic meter
q = electron charge
A = cross-sectional area of the wire
<em>First let's calculate the number of free electrons per cubic meter (n)</em>
Known constants:
density of copper, ρ = 8.95 x 10³kg/m³
molar mass of copper, M = 63.5 x 10⁻³kg/mol
Avogadro's number, Nₐ = 6.02 x 10²³ particles/mol
But;
The number of copper atoms, N, per cubic meter is given by;
N = (Nₐ x ρ / M) -------------(ii)
<em>Substitute the values of Nₐ, ρ and M into equation (ii) as follows;</em>
N = (6.02 x 10²³ x 8.95 x 10³) / 63.5 x 10⁻³
N = 8.49 x 10²⁸ atom/m³
Since there is one free electron per copper atom, the number of free electrons per cubic meter is simply;
n = 8.49 x 10²⁸ electrons/m³
<em>Now let's calculate the drift electron</em>
Known values from question:
A = 5.261 mm² = 5.261 x 10⁻⁶m²
I = 23A
q = 1.6 x 10⁻¹⁹C
<em>Substitute these values into equation (i) as follows;</em>
v =
v =
v = 3.22 x 10⁻⁴ m/s
Therefore, the drift electron is 3.22 x 10⁻⁴ m/s
Answer:
each rotation of the smaller wheel will show 84.382-75.3982=8.9838 inches more than the actual distance
Explanation:
d = Diameter of the wheel
The distance traveled in one rotation of the wheel is the circumference of the wheel
When diameter is 24 inches
Therefore, each rotation of the smaller wheel will show 84.382-75.3982=8.9838 inches more than the actual distance
