Please help on this one!!

Now open the simulation. Activate ""grid"" and ""show numbers"" to read values. Place a 1 nC positive (red color) charge on the

zmey [24]

Answer:

The divergence on the sensor shows the magnitude of the charges

Explanation:

This will increase as length increases since it is said to be proportional to the length. note that test charge is always positive and charge on the grid is positive as indicated (1 nC)

8 0

3 years ago

Which of the following factors affects the pressure of an enclosed gas

PIT_PIT [208]

The answer is:

All the above

The explanation:

The volume and the temperature and the number of particles will affect the pressure of an enclosed gas.

because according to boyle's law when the temperature constant so the pressure and volume of a gas have an inverse relationship, when temperature is constant.

when:

PV = nRT

when p is the pressure

V is the volume

n is number of moles

T is temperature

from this law we can know that there is a relation between P and V and when n has a relation with the number of particles so:

volume , temperature and number of particles affect the pressure of an enclosed gas.

3 0

3 years ago

A ball is thrown with velocity of 10 m/s upwards. If the ball is caught 1 m above its initial position, what is the speed of the

White raven [17]

Answer:

v = 8.96 m/s

Explanation:

Initial speed of the ball, u = 10 m/s

It caught 1 meter above its initial position.

Acceleration due to gravity, $g=-9.8\ m/s^2$

We need to find the final speed of the ball when it is caught. Let is equal to v. To find the value of v, use third equation of motion as :

$v^2-u^2=2as$

$v^2=2as+u^2$

$v^2=2(-9.8)\times 1+(10)^2$

v = 8.96 m/s

So, the speed of the ball when it is caught is 8.96 m/s. Hence, this is the required solution.

6 0

3 years ago

Read 2 more answers

A simple hydraulic lift is made by fitting a piston attached to a handle into a 3.0-cm diameter cylinder. The cylinder is connec

stiv31 [10]

Answer:

Approximately $3.1 \times 10^4 \; \rm N$ (assuming that the acceleration due to gravity is $g = 9.81\; \rm kg \cdot N^{-1}$ .)

Explanation:

Let $A_1$ denote the first piston's contact area with the fluid. Let $A_2$ denote the second piston's contact area with the fluid.

Similarly, let $F_1$ and $F_2$ denote the size of the force on the two pistons. Since the person is placing all her weight on the first piston:

$F_1 = W = m \cdot g = 50\; \rm kg \times 9.81 \; \rm kg \cdot N^{-1} =495\; \rm N$ .

Since both pistons fit into cylinders, the two contact surfaces must be circles. Keep in mind that the area of a square is equal to $\pi$ times its radius, squared:

$\displaystyle A_1 = \pi \times \left(\frac{1}{2} \times 3.0\right)^2 = 2.25\, \pi\;\rm cm^{2}$ .
$\displaystyle A_2 = \pi \times \left(\frac{1}{2} \times 24\right)^2 = 144\, \pi\;\rm cm^{2}$ .

By Pascal's Law, the pressure on the two pistons should be the same. Pressure is the size of normal force per unit area:

$\displaystyle P = \frac{F}{A}$ .

For the pressures on the two pistons to match:

$\displaystyle \frac{F_1}{A_1} = \frac{F_2}{A_2}$ .

$F_1$ , $A_1$ , and $A_2$ have all been found. The question is asking for $F_2$ . Rearrange this equation to obtain:

$\displaystyle F_2 = \frac{F_1}{A_1} \cdot A_2 = F_1 \cdot \frac{A_2}{A_1}$ .

Evaluate this expression to obtain the value of $F_2$ , which represents the force on the piston with the larger diameter:

$\begin{aligned}F_2 &= F_1 \cdot \frac{A_2}{A_1} \\ &= 495\; \rm N \times \frac{2.25\, \pi\; \rm cm^2}{144\, \pi \; \rm cm^2} \approx 3.1 \times 10^4\; \rm N\end{aligned}$ .

6 0

3 years ago

Two helium-filled balloons are released simultaneously at points A and B on the x axis in an earth-based reference frame. Balloo

Vedmedyk [2.9K]

Answer:

The correct answer is C

Explanation:

In this exercise you are asked to analyze the following situation: for a fixed observer, the two balloons are launched at the same time.

If the observer is mobile moving towards the positive side of axis ax we have several

possibilities when starting the movement

* the observer is to the left of the two balloons

* the observer is between the two balloons

* the observer is to the right of the two baloomls

The time it takes for the signal to arrive to know which ball goes first is

v = d / t

t = d / v

If the signal goes at the speed of light, the speed is a constant and the time will depend only on the distance, so we see that the trigger changes depending on the relative position between a given ball and the observer.

Consequently, it will be seen which comes out first, depending on the relative position with the observer.

The correct answer is C

5 0

4 years ago
