An AC circuit has a resistor, capacitor and inductor in series with a 120 V, 60 Hz voltage source. The resistance of the resisto

aliina [53]

Answer:

(i) 3.5385 ohm, 3.768 ohm (ii) 39.89 A (III) 4773.857 W (vi) 348 var (vii) 0.9973 (viii) 4.1796°

Explanation:

We have given voltage V =120 volt

Frequency f=60 Hz

Resistance R =3 ohm

Inductance L =0.01 H

Capacitance C =0.00075 farad

(i) reactance of of inductor $X_L=\omega L=2\pi fL=2\times 3.14\times 60\times 0.01=3.768ohm$

$X_C=\frac{1}{\omega C}=\frac{1}{2\times 3.14\times 60\times 0.00075}=3.5385ohm$

(ii) Total impedance $Z=\sqrt{R^2+(X_L-X_C)^2}=\sqrt{3^2+(3.768-3.5385)^2}=3.008ohm$

Current $i=\frac{V}{Z}=\frac{120}{3.008}=39.89A$

(viii) power factor $cos\Phi =\frac{R}{Z}=\frac{3}{3.008}=0.9973$

(VII) $cos\Phi =0.9973$

$\Phi =4.1796^{\circ}$

So power factor angle is 4.1796°

(iii) Apparent power $P=VICOS\Phi =120\times 39.89\times 0.9973=4773.875W$

(vi) Reactive power $Q=VISIN\Phi =120\times 39.89\times SIN4.17^{\circ}=348var$

5 0

3 years ago

Determine the maximum volume in gallons [gal] of olive oil that can be stored in a closed cylindrical silo with a diameter of 3

Olin [163]

Answer:

V=1601gal

Explanation:

Hello! This problem is solved as follows,

First we must raise the equation that defines the pressure at the bottom of the tank with the purpose of finding the height that olive oil reaches.

This is given as the sum due to the atmospheric pressure (1atm = 101.325kPa), and the pressure due to the weight of the olive oil, taking into account the above, the following equation is inferred.

P=Poil+Patm

P=total pressure or absolute pressure=26psi=179213.28Pa

Patm= the atmospheric pressure =101325Pa

Poil=pressure due to the weight of olive oil=0.86αgh

α=density of water=1000kg/m^3

g=gravity=9.81m/s^2

h= height that olive oil reaches

solving

P=Poil+Patm

P=Patm+0.86αgh

$h=\frac{P-Patm}{0.86\alpha g } =\frac{179214.28-101325}{(0.86)(1000)(9.81)} \\h=9.23m$ [/tex]

Now we can use the equation that defines the volume of a cylinder.

V= $V=\frac{\pi }{4} D^{2} h$

D=3ft=0.9144m

h=9.23m

solving

$V=\frac{\pi }{4} (0.9144)^{2} 9.23=6.06m^3$

finally we use conversion factors to find the volume in gallons

$V=6.06m^3\frac{1000L}{1m^3} \frac{1gal}{3.785L} =1601gal$

3 0

4 years ago

A piston-cylinder assembly contains 2 lb of air at a temperature of 540 degrees R and a pressure of 1 atm. The air is compressed

attashe74 [19]

Answer:

$W=-123.8Btu$

Explanation:

Hello,

In this problem, the piston-cylinder assembly make us state the energy balance as:

$Q-W=\Delta U$

Thus, we must now compute $\Delta U$ in terms of Cv as follows:

$\Delta U=mCv(T_2-T_1)\\\Delta U=2lb*0.173\frac{Btu}{lb*R}*(840R-540R)\\ \Delta U=103.8Btu$

Now, since heat is given off, its sign is negative, thus, the work is computed as:

$W=Q-\Delta U\\W=-20Btu-103.8Btu=-123.8Btu$

This work means that work was done over the system in order to allow the compression.

The suppositions were:

- The change in the internal energy is a function of the temperature.

- Air is an ideal gas.

Best regards.

8 0

4 years ago

A cylindrical specimen of a titanium alloy having an elastic modulus of 107 GPa (15.5 × 106 psi) and an original diameter of 3.7

Keith_Richards [23]

Answer:

the maximum length of specimen before deformation is found to be 235.6 mm

Explanation:

First, we need to find the stress on the cylinder.

Stress = σ = P/A

where,

P = Load = 2000 N

A = Cross-sectional area = πd²/4 = π(0.0037 m)²/4

A = 1.0752 x 10^-5 m²

σ = 2000 N/1.0752 x 10^-5 m²

σ = 186 MPa

Now, we find the strain (∈):

Elastic Modulus = Stress / Strain

E = σ / ∈

∈ = σ / E

∈ = 186 x 10^6 Pa/107 x 10^9 Pa

∈ = 1.74 x 10^-3 mm/mm

Now, we find the original length.

∈ = Elongation/Original Length

Original Length = Elongation/∈

Original Length = 0.41 mm/1.74 x 10^-3

<u>Original Length = 235.6 mm</u>

5 0

3 years ago

Fly thermostat, an automatic temperature controller for homes, learns the patterns for raising and lowering the temperature in a

Lubov Fominskaja [6]

Answer:

The Internet of things

Explanation:

When devices embedded with a network connectivity, software or sensors, are able to exchange data with the manufacturer through the network of physical things, then we say the Internet of things (IoT) has been defined.

Internet of things is when devices like smartphones, sensors and other smart devices are connected together which allows them to exchange data through the network of physical things. By exchanging data, these devices learn new patterns of adaptation.

In this case, the fly thermostat, learns the patterns for raising and lowering the temperature in a house through the Internet of things beacause the sensor has made it possible by automatically observing the temperature pattern of the house.

4 0

4 years ago
