schepotkina [342]
4 years ago
5

Use the image below to measure the blocks. Enter your measurement in centimeters accurate to the 0.1 cm.

Engineering
1 answer:
SOVA2 [1]4 years ago
6 0

Answer:

Pink block = 1.4 cm

Green block= 1.5 cm

Blue block= 1.7 cm

Explanation:

Hi, the ruler is in centimeters, from left to right each long line ( the ones with the number ) is a centimeter.

Since 10 millimeter equals 1 centimeter each short line is a millimeter (0.1 cm)

Knowing this, the measures of each block are.

Pink block = 1.4 cm

Green block= 1.5 cm

Blue block= 1.7 cm

Feel free to ask for more if needed or if you did not understand something.
