Answer:
Vout= 93.3V
Explanation:
For this question, consider circuit in the attachment 1.
This is the circuit of an inverting amplifier. In an inverting amplifier
Vout/Vin= -Rf/Rin
To calculate the Vout, we must find Rin and Vin. For this we must solve the input circuit (attachment 2) using Thevinine theorem. Thevnine theorem states that all voltage sources in a circuit can be replaced by an equivalent voltage source Veq and and all resistances can be replaced by an equivalent resistance Req. To find out Req all voltage sources must be short circuited (attachment 3)
1/Req= 1/R1+1/R2+1/R3
1/Req=1/6+1/3+1/3
Req=6/5
To find out Veq consider circuit in attachment 4. We will solve this circuit using nodal analysis. In nodal analysis, we use the concept that sum of currents entering a node is equal to the sum of currents leaving a node. So,
I1= I2+I3
(10-Veq)/6= (Veq-5)/3+(Veq-10)/3
Veq=8V
Now the input circuit can be simplified as shown in attachment 5. Solve for Vout using equation
Vout/Veq= -Rf/Req
Vout/8= -14/(6/5)
Vout= - 93.3
It is at an angle of 180° from Veq
The all purpose one will work or you could use type C I believe.
Answer:
Enthalpy, hsteam = 2663.7 kJ/kg
Volume, Vsteam = 0.3598613 m^3 / kg
Density = 2.67 kg/ m^3
Explanation:
Mass of steam, m = 1 kg
Pressure of the steam, P = 0.5 MN/m^2
Dryness fraction, x = 0.96
At P = 0.5 MPa:
Tsat = 151.831°C
Vf = 0.00109255 m^3 / kg
Vg = 0.37481 m^3 / kg
hf = 640.09 kJ/kg
hg = 2748.1 kJ/kg
hfg = 2108 kJ/kg
The enthalpy can be given by the formula:
hsteam = hf + x * hfg
hsteam = 640.09 + ( 0.96 * 2108)
hsteam = 2663.7 kJ/kg
The volume of the steam can be given as:
Vsteam = Vf + x(Vg - Vf)
Vsteam = 0.00109255 + 0.96(0.37481 - 640.09)
Vsteam = 0.3598613 m^3 / kg
From the steam table, the density of the steam at a pressure of 0.5 MPa is 2.67 kg/ m^3
Answer:
www stands for world wide web
Explanation:
It will really help you thank you.
Answer:
Plumbing using a one-way check valve to stop water flowing back on a pump when the pump shuts off.
Explanation:
Diodes are like check valves, keeping current from flowing both ways. Used to create d.c. out of a.c by rectification. Also to block flow if d.c. power like a battery is hooked up in reverse polarity.
