Answer: the constant angular velocity of the arms is 86.1883 rad/sec
Explanation:
First we calculate the linear velocity of the single sprinkler;
Area of the nozzle = π/4 × d²
given that d = 8mm = 8 × 10⁻³
Area of the nozzle = π/4 × (8 × 10⁻³)²
A = 5.024 × 10⁻⁵ m²
Now total discharge is dived into 4 jets so discharge for single jet will be;
Q_single = Q / n = 0.006 / 4 = 1.5 × 10⁻³ m³/sec
So using continuity equation ;
Q_single = A × V_single
V_single = Q_single/A
we substitute
V_single = (1.5 × 10⁻³) / (5.024 × 10⁻⁵)
V_single = 29.8566 m/s
Now resolving the forces as shown in the second image,
Vt = Vcos30°
Vt = 29.8566 × cos30°
Vt = 25.8565 m/s
Finally we calculate the angular velocity;
Vt = rω
ω_single = Vt / r
from the given diagram, radius is 300mm = 0.3m
so we substitute
ω_single = 25.8565 / 0.3
ω_single = 86.1883 rad/sec
Therefore the constant angular velocity of the arms is 86.1883 rad/sec
Answer:Arctic circle
Explanation:
Arctic circle is one of the circles of latitude. It is located at the northern region if the equator and passes through more than one continent. These continent includes: North Asia,
Northern America, and
Europe.
In these continent, it passes through eight known counties. These countries includes: Canada, Russia, Norway, Sweden, Finland, Denmark, Alaska and Iceland. It covers 4% of the Earth surface and it's climatic conditions are extreme.
Answer:
magnetic force
Explanation:
when some one gets charged up by maybe static eletricity the person will sustain the energy and the energy will make a force field around the person which can and will attract paper and he will be attractive
D. lost an electron
because they have free electron in the outermost shell which they will like to denote, in order to attain stable configuration
Answer:
(b) the point charge is moved outside the sphere
Explanation:
Gauss' Law states that the electric flux of a closed surface is equal to the enclosed charge divided by permittivity of the medium.
According to this law, any charge outside the surface has no effect at all. Therefore (a) is not correct.
If the point charge is moved off the center, the points on the surface close to the charge will have higher flux and the points further away from the charge will have lesser flux. But as a result, the total flux will not change, because the enclosed charge is the same.
Therefore, (c) and (d) is not correct, because the enclosed charge is unchanged.
