Answer:
a)Cycle time = 2.37 min
b)Numbers of workers =21
c)Stations on the line =24
Explanation:
Given that
Total work content time(TWC) = 50 min
Production rate Rp= 24 units/hr
manning level will be close =1.5
Line balancing efficiency =0.94
a)
Cycle time


Cycle time = 2.37 min
b)
Numbers of workers ,W


W= 21
Numbers of workers =21
c)
Stations on the line(n)
Lets find service time Ts
Ts = Cycle time - Time for repositioning
Ts = Tc- Tr
Ts= 2.37 - 9/ 60 min
Ts= 2.22 min
We know that efficiency


n=23.94 ⇒n=24
n=24
Stations on the line =24
Answer: D
Find the answer in the explanation
Explanation:
Elastic solid will obey Hooke's law which state that the force applied is proportional to the extension provided the elastic limit is not exceeded.
Examples of Newtonian fluid are water, glycerol, honey and all organic solvents
When comparing solids to fluids, the below statement is true
We can therefore conclude that
For elastic solids, stress is linearly related to strain, and for Newtonian fluids, stress is linearly related to strain rate
Answer:
See step by step explanations for answer.
Explanation:
600 megawatts =
568 690.272 btu / second
thermal eficiency=work done/Heat supllied
0.38=568690.272/Heat supplied
Heat supplied=1496553.35btu /s
heat emmitted to the atmosphere=heat supplied -work done=(1496553.35-568690.272)=927863.1 btu/s
feed rate=(1496553.35)/12000=124.71 lb/s =10775184.1056 lb/day=5 387.472 ton / day
sulphur content released=(0.03*124.71)/(1.496553)=2.5 lb SO2/million Btu of heat input
so
the degree (%) of sulfur dioxide control needed to meet an emission standard=(2.5/0.15)*100=1666.67 %
the CO2 emission rate=220*(1.496553) =329.241 lb/s =12 903.0802 metric ton / day
