A horizontal curve is being designed through mountainous terrain for a four-lane road with lanes that are 10 ft wide. The centra

l angle (I) is known to be 40 degrees, the tangent is 520 ft, and the stationing of the tangent intersection (PI) is 2600 + 00. Under specified conditions and vehicle speed, the roadway surface is determined to have a coefficient of side friction of 0.08, and the curve’s superelevation is 0.09 ft/ft. What is the stationing of the PC and PT and what is the safe vehicle speed?

Engineering
1 answer:
ioda3 years ago
5 0

Answer:

our answer is attached below

Explanation:
