g A steel water pipe has an inner diameter of 12 in. and a wall thickness of 0.25 in. Determine the longitudinal and hoop stress

zvonat [6]

Answer:

a) $\mathbf{\sigma _ 1 = 4800 psi}$

$\mathbf{ \sigma _2 = 0}$

b) $\mathbf{\sigma _ 1 = 6000 psi}$

$\mathbf{ \sigma _2 = 3000 psi}$

Explanation:

Given that:

diameter d = 12 in

thickness t = 0.25 in

the radius = d/2 = 12 / 2 = 6 in

r/t = 6/0.25 = 24

24 > 10

Using the thin wall cylinder formula;

The valve A is opened and the flowing water has a pressure P of 200 psi.

So;

$\sigma_{hoop} = \sigma _ 1 = \frac{Pd}{2t}$

$\sigma_{long} = \sigma _2 = 0$

$\sigma _ 1 = \frac{Pd}{2t} \\ \\ \sigma _ 1 = \frac{200(12)}{2(0.25)}$

$\mathbf{\sigma _ 1 = 4800 psi}$

b)The valve A is closed and the water pressure P is 250 psi.

where P = 250 psi

$\sigma_{hoop} = \sigma _ 1 = \frac{Pd}{2t}$

$\sigma_{long} = \sigma _2 = \frac{Pd}{4t}$

$\sigma _ 1 = \frac{Pd}{2t} \\ \\ \sigma _ 1 = \frac{250*(12)}{2(0.25)}$

$\mathbf{\sigma _ 1 = 6000 psi}$

$\sigma _2 = \frac{Pd}{4t} \\ \\ \sigma _2 = \frac{250(12)}{4(0.25)}$

$\mathbf{ \sigma _2 = 3000 psi}$

The free flow body diagram showing the state of stress on a volume element located on the wall at point B is attached in the diagram below
