Answer:
e = 3.97*10^-4
Explanation:
1.8 mm = 0.0018 m
2.6*10^4 mm = 26 m
Elongation is The ratio between the stretched length and the original length.
e = L/L0
This is calculated with Hooke's law:
e = σ/E
Where
σ: normal stress
E: elastic constant
σ = P/A
Where
P: normal load
A: cross section
A = π/4 * d^2
Therefore:
e = P / (A * E)
e = 4 * P / (π * d^2 * E)
e = 4 * 290 / (π * 0.0018^2 * 207*10^9) = 3.97*10^-4
Answer: Both Technicians
Explanation:
When testing a spring break it is advisable to Step on and off the brake, with the engine off, the parking brake knob is expected to pop out when air pressure falls between 20-40 psi.
Go under the vehicle and pull the spring brakes.
Turn on the engine back and pump the brake pedal down to the floor. To test the spring breaks
Answer:
Option c)
Explanation:
a.The carbon content of eutectoid steel, which is an carbon- iron alloy, is in between 0.80-0.83%
b. In hypoeutectoid steel, the carbon composition is less than 0.80% and is approximately 0.76%
c. In hypereutectoid steel, the carbon composition ranges from 0.80% - 2.0%
d. In wrought iron, the iron composition is quite low about 0.08%
The specific grounding and bonding requirements for an information technology room are located in Article 645.
<h3>What does NEC stand for?</h3>
The National Electrical Code (NEC) is a collection of requirements for the secure installation of electrical wiring in the US that are routinely updated.
Bonding is the joining of conductors that do not convey current, such as enclosures and buildings. Bonded systems are attached to the earth by grounding. To protect persons and property from electric risks, both are required.
Article 645 compliance is optional. The two main pardons provided by Article 645 are. First, underneath a raised floor, non-plenum-rated cables are acceptable. Second, cables, boxes, and similar items for the mentioned IT equipment are exempt from the need for security. sted IT equipment cables, boxes, and the like are not required to be secured in place.
