Whats happening in this diagram?

Physics

1 answer:

yaroslaw [1]4 years ago

6 0

The ship sends waves to the bottom of the ocean so if this waves hit any solid particle it reflect back to the main ship , and the ship send the divers to explore

You might be interested in

What is all matter made up of?

aliya0001 [1]

All matter is made up of atoms

3 0

4 years ago

Read 2 more answers

Please help !!

nikitadnepr [17]

If the speed is constant, the acceleration a must be zero. Since force F = m•a, the total force must be zero.
In a 1D case, work W is the product of force F and distance d: W = F • d.
Since there is no more information given about friction or air resistance, I have to assume you are looking for the work done by the total force, wich is also zero.

3 0

3 years ago

Two forces,

serg [7]

First compute the resultant force F:

$\mathbf F_1=(5.90\,\mathbf i-5.60\,\mathbf j)\,\mathrm N$

$\mathbf F_2=(4.65\,\mathbf i-5.55\,\mathbf j)\,\mathrm N$

$\implies\mathbf F=\mathbf F_1+\mathbf F_2=(10.55\,\mathbf i-11.15\,\mathbf j)\,\mathrm N$

Then use Newton's second law to determine the acceleration vector $\mathbf a$ for the particle:

$\mathbf F=m\mathbf a$

$(10.55\,\mathbf i-11.15\,\mathbf j)\,\mathrm N=(2.10\,\mathrm{kg})\mathbf a$

$\mathbf a\approx(5.02\,\mathbf i-5.31\,\mathbf j)\dfrac{\rm m}{\mathrm s^2}$

Let $\mathbf x(t)$ and $\mathbf v(t)$ denote the particle's position and velocity vectors, respectively.

(a) Use the fundamental theorem of calculus. The particle starts at rest, so $\mathbf v(0)=0$ . Then the particle's velocity vector at t = 10.4 s is

$\mathbf v(10.4\,\mathrm s)=\mathbf v(0)+\displaystyle\int_0^{10}\mathbf a(u)\,\mathrm du$

$\mathbf v(10.4\,\mathrm s)=\left((5.02\,\mathbf i-5.31\,\mathbf j)u\,\dfrac{\rm m}{\mathrm s^2}\right)\bigg|_{u=0}^{u=10.4}$

$\mathbf v(10.4\,\mathrm s)\approx(52.2\,\mathbf i-55.2\,\mathbf j)\dfrac{\rm m}{\rm s}$

If you don't know calculus, then just use the formula,

$v_f=v_i+at$

So, for instance, the velocity vector at t = 10.4 s has x-component

$v_{f,x}=0+\left(5.02\dfrac{\rm m}{\mathrm s^2}\right)(10.4\,\mathrm s)=52.2\dfrac{\rm m}{\mathrm s^2}$

(b) Compute the angle $\theta$ for $\mathbf v(10.4\,\mathrm s)$ :

$\tan\theta=\dfrac{-55.2}{52.2}\implies\theta\approx-46.6^\circ$

so that the particle is moving at an angle of about 313º counterclockwise from the positive x axis.

(c) We can find the velocity at any time t by generalizing the integral in part (a):

$\mathbf v(t)=\mathbf v(0)+\displaystyle\int_0^t\mathbf a\,\mathrm du$

$\implies\mathbf v(t)=\left(5.02\dfrac{\rm m}{\mathrm s^2}\right)t\,\mathbf i+\left(-5.31\dfrac{\rm m}{\mathrm s^2}\right)t\,\mathbf j$

Then using the fundamental theorem of calculus again, we have

$\mathbf x(10.4\,\mathrm s)=\mathbf x(0)+\displaystyle\int_0^{10.4}\mathbf v(u)\,\mathrm du$

where $\mathbf x(0)=(-1.75\,\mathbf i+4.15\,\mathbf j)\,\mathrm m$ is the particle's initial position. So we get

$\mathbf x(10.4\,\mathrm s)=(-1.75\,\mathbf i+4.15\,\mathbf j)\,\mathrm m+\displaystyle\int_0^{10.4}\left(\left(5.02\dfrac{\rm m}{\mathrm s^2}\right)u\,\mathbf i+\left(-5.31\dfrac{\rm m}{\mathrm s^2}\right)u\,\mathbf j\right)\,\mathrm du$

$\mathbf x(10.4\,\mathrm s)=(-1.75\,\mathbf i+4.15\,\mathbf j)\,\mathrm m+\dfrac12\left(\left(5.02\dfrac{\rm m}{\mathrm s^2}\right)u^2\,\mathbf i+\left(-5.31\dfrac{\rm m}{\mathrm s^2}\right)u^2\,\mathbf j\right)\bigg|_{u=0}^{u=10.4}$

$\mathbf x(10.4\,\mathrm s)\approx(542\,\mathbf i-570\,\mathbf j)\,\mathrm m$

So over the first 10.4 s, the particle is displaced by the vector

$\mathbf x(10.4\,\mathrm s)-\mathbf x(0)\approx(270\,\mathbf i-283\,\mathbf j)\,\mathrm m-(-1.75\,\mathbf i+4.15\,\mathbf j)\,\mathrm m\approx(272\,\mathbf i-287\,\mathbf j)\,\mathrm m$
