BabaBlast [244]
3 years ago
9

Determine the average power, complex power and power factor (including whether it is leading or lagging) for a load circuit whos

e voltage and current at its input terminals are given by: v(t) = 100cos(377t-30)v, i(t) = 2.5cos(377t-60)A

Engineering
2 answers:
Charra [1.4K]3 years ago
6 0

Answer:

Average power: 108.25 W

Complex power: 125 VA

Power factor: 0.866

Refer below for the explanation.

Explanation:

Refer to the picture for brief explanation.

Paul [167]3 years ago
4 0

Answer:

Average power = 108.25W

Complex power = 125W

PF = 0.866

Explanation:

Check attachment for step by step instructions.

You might be interested in
Calculate the kinetic energy in kJ of an automobile (3,000 lb) travelling at 60 miles per hour.
AlladinOne [14]

Answer:

K = 18.26 KJ

Explanation:

See it in the pic.

4 0
3 years ago
2. Similar to problem 1, assume your computer system has a 32-bit byte-addressable architecture where addresses and data are eac
andreev551 [17]

Question:

The question is not complete. The question to answer was not added. See below the possible question and the answer.

a. How many blocks are in the cache with this new arrangement?

b. Calculate the number of bits in each of the Tag, Index, and Offset fields of the memory address.

C. Using the values calculated in part b, what is the actual total size of the cache including data, tags, and valid bits?

Answer:

(a) Number of blocks =  512 blocks

(b) Tag is 18

(c)  Total size of the cache = 8388608 bytes

Explanation:

a .

block size = 32 bytes

cache size = 16384 bytes

No.of blocks = 16384 / 32

No.pf blocks = 512 blocks

b.

Total address size = 32 bits

Address bits = Tag + Line index +block offset

Block Size = 32 bytes.

So block size = 25 bytes.

Hence Offset is 5

No . of Cache blocks = 512 blocks = 29 blocks

Hence line offset is 9

We know that Address bits = Tag + Line index +block offset

So , 32 =tag+9+5

tag = 32-(9+5)

So Tag is 18

c.

Data bits = 32 bits

Tag=18 bits

Valid bit is 1 bit

so Total cache size = 25+218+20

                                  = 223

                                  =8388608 bytes

7 0
4 years ago
As Becky was driving "Old Betsy," the family station wagon, the engine finally quit, being worn out after 171,000 miles. It can
andriy [413]

Answer:

1) 4.361 x 10 raised to power 8 revolutions

2) 1.744 x 10 raised to power 9 firings

3) 2.18 x 10 raised to power 8  intake strokes

Explanation:

The step by step explanation is as shown in the attachment

8 0
4 years ago
Suppose there are 76 packets entering a queue at the same time. Each packet is of size 5 MiB. The link transmission rate is 2.1
tia_tia [17]

Answer:

938.7 milliseconds

Explanation:

Since the transmission rate is in bits, we will need to convert the packet size to Bits.

1 bytes = 8 bits

1 MiB = 2^20 bytes = 8 × 2^20 bits

5 MiB = 5 × 8 × 2^20 bits.

The formula for queueing delay of <em>n-th</em> packet is :  (n - 1) × L/R

where L :  packet size = 5 × 8 × 2^20 bits, n: packet number = 48 and R : transmission rate =  2.1 Gbps = 2.1 × 10^9 bits per second.

Therefore queueing delay for 48th packet = ( (48-1) ×5 × 8 × 2^20)/2.1 × 10^9

queueing delay for 48th packet = (47 ×40× 2^20)/2.1 × 10^9

queueing delay for 48th packet = 0.938725181 seconds

queueing delay for 48th packet = 938.725181 milliseconds = 938.7 milliseconds

4 0
3 years ago
How many ( 1/8") in one inch?
Anna35 [415]

Answer:

1 inch

Explanation:

There for there are 8 1/8 inch that make up 1 inch so the answer is 1 inch

4 0
3 years ago
Read 2 more answers
