A flat coil of wire is placed in a uniform magnetic field that is in the y-direction.

Physics

1 answer:

Kitty [74]2 years ago

7 0

Answer:

The correct answer is c

Explanation:

Flow is defined by

Ф = B . A

bold letters indicate vectors.

The magnetic field is directed to the y axis, The area of the coil is represented by a vector normal to the plane of the coil, so to have a flux

i.i = j.j = k.k = 1

and the tori scalar products are zero

a) If the coil must be in the xy plane so that its normal vector is in the Z axis, so there is no flux

b) if the coil is in the plane yz the normal veto is in the x axis, so the flux is zero

C) If the coil is in XZ, the normal vector points in the y direction, usually the scalar product is one and there is a flux in this configuration

The correct answer is c

You might be interested in

What is a superpositional principle

natali 33 [55]

the principle that in a series of stratified sedimentary rocks the lowest stratum is the oldest. 2. n. the displacement of any point due to the superposition of wave systems is equal to the sum of the displacements of the individual waves at that point.

7 0

2 years ago

Read 2 more answers

Using complete sentences, explain why graphs are so important to scientists.

morpeh [17]

Answer: It keeps them organized

Explanation: ... ew

5 0

2 years ago

Can someone help me with this ? I need proper explanation ~

Pepsi [2]

Answer:

Explanation:

3 0

2 years ago

How to find a planet’s gravitational field strength using its radius?

grin007 [14]

The gravitational field strength is approximately equal to 10 N.

Explanation:

Gravitational field strength is the measure of gravitational force acting on any object placed on the surface of the planet. Generally, the mass of the object is considered as 1 kg.

So the gravitational field strength will be equal to the gravitational force acting on the object.

The formula for gravitational field strength is

$g = \frac{F}{m}$

Here g is the gravitational field strength, m is the mass of the object placed on the surface and F is the gravitational force acting on the object.

Since, the mass of any object placed on the surface of earth will be negligible compared to the mass of Earth, so the mass of the object is considered as 1 kg.

Then the g = F

And $F =\frac{GMm}{r^{2} }$

Here G is the gravitational constant, M is the mass of Earth and m is the mass of the object placed on the surface, while r is the radius of the Earth.

$g = F = \frac{6 \times 10^{24} \times 6.67 \times 10^{-11} \times 1}{(6.6 \times 10^{6}) ^{2} }$

$g = 0.977 \times 10^1= 9.77\ N$

So, the gravitational field strength is approximately equal to 10 N.

5 0

2 years ago

For installation with a 25-kVA, 3-phase transformer, a 440-volt primary, and a 120-volt secondary. Calculate the maximum overcur

andre [41]

Answer:

41.053 A

Explanation:

given,

three phase kVA = 25-kVA

voltage = 440 Volt

current = ?

To determine three phase kVA when volts and amperes are know

three phase kVA = 1.73 x V x I

$I = \dfrac{three\ phase\ kVA}{1.73 \times V}$

$I = \dfrac{25000}{1.73 \times 440}$

I = 32.84 A

the maximum overcurrent protection value is equal to

= 125 % of I

= 1.25 x 32.84

= 41.053 A

4 0

2 years ago
