Need help with this question pls help.

For a column that is pinned at both ends, the critical buckling load can be calculated as, Pcr = π2 E I /L^2 where E is Young's

gulaghasi [49]

When a slender member is subjected to an axial compressive load, it may fail by a ... Consider a column of length, L, cross-sectional Moment of Inertia, I, having Young's Modulus, E. Both ends are pinned, meaning they can freely rotate ... p2EI L2 ... scr, is the Euler Buckling Load divided by the columns cross-sectional area

6 0

4 years ago

Interpret the assembly program below: MOV R3,R0;

Reika [66]

Answer:

Explanation:

1. With the operands R0, R1, the program would compute AND operation and ADD operation .

2. The operands could truly be signed 2's complement encoded (i.e Yes) .

3. The overflow truly occurs when two numbers that are unsigned were added and the result is larger than the capacity of the register, in that situation, overflow would occur and it could corrupt the data.

When the result of an operation is smaller in magnitude than the smallest value represented by the data type, then arithmetic underflow will occur.

7 0

4 years ago

6.28 A six-lane freeway (three lanes in each direction) in rolling terrain has 10-ft lanes and obstructions 4 ft from the right

dimulka [17.4K]

Answer:

Assume Base free flow speed (BFFS) = 70 mph

Lane width = 10 ft

Reduction in speed corresponding to lane width, fLW = 6.6 mph

Lateral Clearance = 4 ft

Reduction in speed corresponding to lateral clearance, fLC = 0.8 mph

Interchanges/Ramps = 9/ 6 miles = 1.5 /mile

Reduction in speed corresponding to Interchanges/ramps, fID = 5 mph

No. of lanes = 3

Reduction in speed corresponding to number of lanes, fN = 3 mph

Free Flow Speed (FFS) = BFFS – fLW – fLC – fN – fID = 70 – 6.6 – 0.8 – 3 – 5 = 54.6 mph

Peak Flow, V = 2000 veh/hr

Peak 15-min flow = 600 veh

Peak-hour factor = 2000/ (4*600) = 0.83

Trucks and Buses = 12 %

RVs = 6 %

Rolling Terrain

fHV = 1/ (1 + 0.12 (2.5-1) + 0.06 (2.0-1)) = 1/1.24 = 0.806

fP = 1.0

Peak Flow Rate, Vp = V / (PHV*n*fHV*fP) = 2000/ (0.83*3*0.806*1.0) = 996.54 ~ 997 veh/hr/ln

Vp < (3400 – 30 FFS)

S = FFS

S = 54.6 mph

Density = Vp/S = (997) / (54.6) = 18.26 veh/mi/ln

7 0

3 years ago

What does the branch of physics include

cricket20 [7]

Answer:

The branches of physics are;

Classical physics
Modern physics
Nuclear physics
Atomic physics
Geophysics
Biophysics

Explanation:

Physics is a branch of science that studies nature, properties of matter and energy. The subjects in study are; mechanics, light, heat, light, sound, electricity, properties of atoms and magnetism.

The common branches are;

Thermodynamics which that studies heat, how it is transferred and effects
Sound that studies production, properties and application of sound waves
Light that deals with properties,pysical aspects and objects that utilize light
Electricity and magnetism that studies charges, their effects and relation with magnetism
Classical physics that studies laws of motion and gravity
Modern physics that study theory of relativity and quantum mechanics

4 0

3 years ago

Three tugboats are used to turn a barge in a narrow channel. To avoid producing any net translation of the barge, the forces app

stiks02 [169]

Answer:

a) Fb= 275.77 lb Fc= 142.75 lb

b) M = -779.97 lb.ft (i.e. 779.97 lb.ft in clockwise direction)

c) Fax = 195 lb

Fay = 337.75 lb

Fbx = 195 lb

Fby = 195 lb

Explanation:

Question: Three tugboats are used to turn a barge in a narrow channel. To avoid producing any net translation of the barge, the forces applied should be couples. The tugboat at point A applies a 390 lb force.

(a) Determine FB and FC so that only couples are applied.

(b) Using your answers to Part (a), determine the resultant couple moment that is produced.

(c) Resolve the forces at A and B into x and y components, and identify the pairs of forces that constitute couples.

Solution:

<u>For this problem Right hand side is positive X direction and Upwards is positive Y direction. Couples and moments will be considered positive in counterclockwise direction.</u>

<u />

a) For no translation condition

∑ $F_{x} = 0$ & ∑ $F_{y} = 0$
