All categories

3 years ago

Teachers

Engineering

1 answer:

IRINA_888 [86]3 years ago

5 0

Uh I’m just gonna say yes because I think this is just something random

You might be interested in

A certain power-supply filter produces an output with a ripple of 100 mV peak-to-peak and a dc value of 20 V. The ripple factor

Oksanka [162]

Answer: the ripple factor is 0.005

Explanation:

Given the data in the question;

we know that expression of ripple factor is;

r = Vr(pp) / Vdc

where Vr(pp) the peak to peak is ripple voltage ( 100mv = 0.1 V)

and Vdc is the dc value of the filter output voltage ( 20 V)

so we substitute our given values;

r = 0.1 / 20

r = 0.005

Therefore; the ripple factor is 0.005

8 0

3 years ago

A 2m high sandy fill material was placed loosely at a relative density of 47%. Laboratory studies indicated that the maximum and

Llana [10]

Answer:

Explanation:To find the solution we must first make the transformations to international units,

In this way:

Inches of length (L) to feet =

So we can identify the area by hour:

Once the area is identified, we now identify the number of passes required,

Passes required = Area x number of passes

We transform speed to international units

So we can identify the covered area

where

m = drum widht

p = efficiency

In this way we obtain the number of rollers given by:

No. of Rollers = Passes required / covered area

No of rollers = 48136/40269

No of rollers = 1.19, that is, 2

Read more on Brainly.com - brainly.com/question/13686900#readmore.

6 0

3 years ago

One problem with organic equations is that we tend to focus on what is happening to onemolecule at a time, we forget that there

stellarik [79]

Answer:

1 2 200 000 000 000 000 000 000 (20 zeros) molecules

Explanation:

Molar mass of 1-butanol = 74.121 g/mol

number of moles = mass given / molar mass

where mass given = 1.5 g

number of mole = 1.5 g / (74.121g/mol ) = 0.0202 moles

number of moles = number of molecules / Avogadro's constant

where Avogadro's = 6.022 × 10²³ mol⁻¹

number of moles = 6.022 × 10²³ × 0.0202 moles = 1 2 200 000 000 000 000 000 000 (20 zeros) molecules

3 0

3 years ago

11. Amphetamines that keep drivers awake also help with coordination and reaction time.

RSB [31]

Answer:

O B false

Explanation:

dont do drugs

5 0

3 years ago

Read 2 more answers

Shear plane angle and shear strain: In an orthogonal cutting operation, the tool has a rake angle = 16°. The chip thickness befo

Oduvanchick [21]

Answer:

shear plane angle Ф = 26.28°

shear strain 2.20

Explanation:

given data

angle = 16°

chip thickness t1 = 0.32 mm

cut yields chip thickness t2 = 0.72 mm

solution

we get here first chip thickness ratio that is

chip thickness ratio = $\frac{t1}{t2}$ ................. 1

put here value

chip thickness ratio = $\frac{0.32}{0.72}$

chip thickness ratio r = 0.45

so here shear angle will be Ф

tan Ф = $\frac{r*cos\alpha }{1-rsin\alpha}$ ............2

tan Ф = $\frac{0.45*cos16 }{1-rsin16}$

tan Ф = 0.4938

Ф = 26.28°

and

now we get shear strain that is

shear strain r = cot Ф + tan (Ф - α ) ................3

shear strain r = cot(26.28) + tan (26.28 - 16 )

shear strain r = 2.20

6 0

4 years ago
