The <em>estimated</em> displacement of the center of mass of the olive is .
<h3>Procedure - Estimation of the displacement of the center of mass of the olive</h3>
In this question we should apply the definition of center of mass and difference between the coordinates for <em>dynamic</em> () and <em>static</em> conditions () to estimate the displacement of the center of mass of the olive ():
(1)
Where:
- - x-Coordinate of the i-th element of the system, in meters.
- - y-Coordinate of the i-th element of the system, in meters.
- - x-Component of the net force applied on the i-th element, in newtons.
- - y-Component of the net force applied on the i-th element, in newtons.
- - Mass of the i-th element, in kilograms.
- - Gravitational acceleration, in meters per square second.
If we know that , , , , , and , then the displacement of the center of mass of the olive is:
<h3>Dynamic condition
</h3>
<h3>Static condition</h3><h3>
</h3><h3>
</h3><h3 /><h3>Displacement of the center of mass of the olive</h3>
The <em>estimated</em> displacement of the center of mass of the olive is .
To learn more on center of mass, we kindly invite to check this verified question: brainly.com/question/8662931
Kinetic and potential energies are found in all objects. If an object is moving, it is said to have kinetic energy (KE). Potential energy (PE) is energy that is "stored" because of the position and/or arrangement of the object.
Answer:
497.143 nm.
Explanation:
Diffraction grating experiment is actually done by passing light through diffraction glasses, the passage of the light causes some patterns which can be seen on the screen. This is because light is a wave and it can spread.
The solution to the question is through the use of the formula in the equation (1) below;
Sin θ = m × λ. ---------------------------------(1).
Where m takes values from 0, 1, 2, ...(that is the diffraction grating principal maxima).
Also, m × λ = dc/ B -------------------------------------------(2).
We are to find the second wavelength, therefore;
λ2 =( m1/c1) × (c2/m2) × λ1 ------------------------(3).
Where c1 and c2 are the order maximum and m = order numbers. Hence;
λ2 = (1/ .350) × (.870/3) × 600 = 497.143 nm.
Answer:
M₁₂ = 1.01 10⁻⁴ H
, Fem = 3.54 10⁻³ V
Explanation:
The mutual inductance between two systems is
M₁₂ = N₂ Ф₁₂ / I₁
where N₂ is the number of turns of the inner solenoid N₂ = 21.0, i₁ the current that flows through the outer solenoid I₁ = 35.0 A / s and fi is the flux of the field of coil1 that passes through coil 2
the magnetic field of the coil1 is
B = μ₀ n I₁ = μ₀ N₁/l I₁
the flow is
Φ = B A₂
the area of the second coil is
A₂ = π d₂ / 4
Φ = μ₀ N₁ I₁ / L π d² / 4
we substitute in the first expression
M₁₂ = N₂ μ₀ N₁ / L π d² / 4
M₁₂ = μ₀ N₁ N₂ π d² / 4L
d = 0.170 cm = 0.00170 m
L = 4.00 cm = 0.00400 m
let's calculate
M₁₂ = 4π 10⁻⁷ 6750 21 π 0.0017²/ (4 0.004)
M₁₂ = π² 0.40966 10⁻⁷ / 0.004
M₁₂ = 1.01 10⁻⁴ H
The electromotive force is
Fem = - M dI₁ / dt
Fem = - 1.01 10⁻⁴ 35.0
Fem = 3.54 10⁻³ V
Use equation, force×distance=work done(a form of energy).
force=work done÷distance= 2240÷40=56N
