Answer:
B.
Explanation:
For a given set of input values, A NAND gate produces exactly the same values as an OR gate with inverted inputs.
The truth table for a NAND gate with 2 inputs is as follows:
0 0 1
0 1 1
1 0 1
1 1 0
The truth table for an OR gate, is as follows:
0 0 0
0 1 1
1 0 1
1 1 1
If we add two extra columns for inverted inputs, the truth table will be this one:
0 0 1 1 1
0 1 1 0 1
1 0 0 1 1
1 1 0 0 0
which is the same as for the NAND gate, not the opposite, so the statement is false.
This means that the right choice is B.
Answer: 100% (double)
Explanation:
The question tells us two important things:
- Mass remains constant
- Volume remains constant
(We can think in a gas enclosed in a closed bottle, which is heated, for instance)
In this case we know that, as always the gas can be considered as ideal, we can apply the general equation for ideal gases, as follows:
- State 1 (P1, V1, n1, T1) ⇒ P1*V1 = n1*R*T1
- State 2 (P2, V2, n2, T2) ⇒ P2*V2 = n2*R*T2
But we know that V1=V2 and that n1=n2, som dividing both sides, we get:
P1/P2 = T1/T2, i.e, if T2=2 T1, in order to keep both sides equal, we need that P2= 2 P1.
This result is just reasonable, because as temperature measures the kinetic energy of the gas molecules, if temperature increases, the kinetic energy will also increase, and consequently, the frequency of collisions of the molecules (which is the pressure) will also increase in the same proportion.
Answer:
F = 33,324,295.32N
Explanation:
We will first of all find the height at which the plate is inclined. We use sine rule in this case
SinΘ = Opp/hyp
Opp=h, hyp=19m, Θ=35°
h = 19xSin35 = 10.899m
Therefore height h=10.899+4 = 14.899m
We then Calculate Area of the plate
Area = 12x19 = 228m²
Finally, we use an online software to calculate the Hydrostatic pressure
The result from the online computation is attached.
The pressure is p = 146159.19Pa
But pressure p is
Pressure=Force/Area
Making Force the subject
Hydrostatic Force = Pressure x Area
F= 146159.19 x 228 = 33,324,295.32N
F = 33,324,295.32N
Answer:
The efficiency of a DC generator is maximum when those losses proportional to the square of the load current are equal to the constant losses of the DC generator. This relation applies equally well to all rotating machines, regardless of the type of machine.
Explanation:
