Which two features are part of a line graph

Physics

1 answer:

Zina [86]3 years ago

4 0

Answer:iiiiiiiiiii have no idea

Explanation:

You might be interested in

Sphere A of mass 0.600 kg is initially moving to the right at 4.00 m/s. sphere B, of mass 1.80 kg is initially to the right of s

anzhelika [568]

A) The velocity of sphere A after the collision is 1.00 m/s to the right

B) The collision is elastic

C) The velocity of sphere C is 2.68 m/s at a direction of $-5.2^{\circ}$

D) The impulse exerted on C is 4.29 kg m/s at a direction of $-5.2^{\circ}$

E) The collision is inelastic

F) The velocity of the center of mass of the system is 4.00 m/s to the right

Explanation:

We can solve this part by using the principle of conservation of momentum. The total momentum of the system must be conserved before and after the collision:

$p_i = p_f\\m_A u_A + m_B u_B = m_A v_A + m_B v_B$

$m_A = 0.600 kg$ is the mass of sphere A

$u_A = 4.00 m/s$ is the initial velocity of the sphere A (taking the right as positive direction)

$v_A$ is the final velocity of sphere A

$m_B = 1.80 kg$ is the mass of sphere B

$u_B = 2.00 m/s$ is the initial velocity of the sphere B

$v_B = 3.00 m/s$ is the final velocity of the sphere B

Solving for vA:

$v_A = \frac{m_A u_A + m_B u_B - m_B v_B}{m_A}=\frac{(0.600)(4.00)+(1.80)(2.00)-(1.80)(3.00)}{0.600}=1.00 m/s$

The sign is positive, so the direction is to the right.

To verify if the collision is elastic, we have to check if the total kinetic energy is conserved or not.

Before the collision:

$K_i = \frac{1}{2}m_A u_A^2 + \frac{1}{2}m_B u_B^2 =\frac{1}{2}(0.600)(4.00)^2 + \frac{1}{2}(1.80)(2.00)^2=8.4 J$

After the collision:

$K_f = \frac{1}{2}m_A v_A^2 + \frac{1}{2}m_B v_B^2 = \frac{1}{2}(0.600)(1.00)^2 + \frac{1}{2}(1.80)(3.00)^2=8.4 J$

The total kinetic energy is conserved: therefore, the collision is elastic.

Now we analyze the collision between sphere B and C. Again, we apply the law of conservation of momentum, but in two dimensions: so, the total momentum must be conserved both on the x- and on the y- direction.

Taking the initial direction of sphere B as positive x-direction, the total momentum before the collision along the x-axis is:

$p_x = m_B v_B = (1.80)(3.00)=5.40 kg m/s$

While the total momentum along the y-axis is zero:

$p_y = 0$

We can now write the equations of conservation of momentum along the two directions as follows:

$p_x = p'_{Bx} + p'_{Cx}\\0 = p'_{By} + p'_{Cy}$ (1)

We also know the components of the momentum of B after the collision:

$p'_{Bx}=(1.20)(cos 19)=1.13 kg m/s\\p'_{By}=(1.20)(sin 19)=0.39 kg m/s$

So substituting into (1), we find the components of the momentum of C after the collision:

$p'_{Cx}=p_B - p'_{Bx}=5.40 - 1.13=4.27 kg m/s\\p'_{Cy}=p_C - p'_{Cy}=0-0.39 = -0.39 kg m/s$

So the magnitude of the momentum of C is

$p'_C = \sqrt{p_{Cx}^2+p_{Cy}^2}=\sqrt{4.27^2+(-0.39)^2}=4.29 kg m/s$

Dividing by the mass of C (1.60 kg), we find the magnitude of the velocity:

$v_c = \frac{p_C}{m_C}=\frac{4.29}{1.60}=2.68 m/s$

And the direction is

$\theta=tan^{-1}(\frac{p_y}{p_x})=tan^{-1}(\frac{-0.39}{4.27})=-5.2^{\circ}$

The impulse imparted by B to C is equal to the change in momentum of C.

The initial momentum of C is zero, since it was at rest:

$p_C = 0$

While the final momentum is:

$p'_C = 4.29 kg m/s$

So the magnitude of the impulse exerted on C is

$I=p'_C - p_C = 4.29 - 0 = 4.29 kg m/s$

And the direction is the angle between the direction of the final momentum and the direction of the initial momentum: since the initial momentum is zero, the angle is simply equal to the angle of the final momentum, therefore $-5.2^{\circ}$ .

To check if the collision is elastic, we have to check if the total kinetic energy is conserved or not.

The total kinetic energy before the collision is just the kinetic energy of B, since C was at rest:

$K_i = \frac{1}{2}m_B u_B^2 = \frac{1}{2}(1.80)(3.00)^2=8.1 J$

The total kinetic energy after the collision is the sum of the kinetic energies of B and C:

$K_f = \frac{1}{2}m_B v_B^2 + \frac{1}{2}m_C v_C^2 = \frac{1}{2}(1.80)(1.20)^2 + \frac{1}{2}(1.60)(2.68)^2=7.0 J$

Since the total kinetic energy is not conserved, the collision is inelastic.

Here we notice that the system is isolated: so there are no external forces acting on the system, and this means the system has no acceleration, according to Newton's second law:

$F=Ma$

Since F = 0, then a = 0, and so the center of mass of the system moves at constant velocity.

Therefore, the centre of mass after the 2nd collision must be equal to the velocity of the centre of mass before the 1st collision: which is the velocity of the sphere A before the 1st collision (because the other 2 spheres were at rest), so it is simply 4.00 m/s to the right.

Learn more about momentum and collisions:

brainly.com/question/6439920

brainly.com/question/2990238

brainly.com/question/7973509

brainly.com/question/6573742

#LearnwithBrainly

8 0

3 years ago

You observe two cars traveling in the same direction on a long, straight section of Highway 5. The red car is moving at a consta

Romashka-Z-Leto [24]

Answer:

a) 3.66 s

b) 124.4 m

c) 3.12s

Explanation:

Given that

Speed of the Red Car, v₁ = 34 m/s

Speed of the Blue Car, v₂ = 28 m/s

Distance between the two cars, d = 22 m

The difference between the speed of the cars is: 34 - 28 = 6 m/s

From this, we can deduce that the red car will be catching up to the blue car at a speed of 6 m/s.

If we divide the distance by the difference in speed. This becomes

d/v = 22/6 = 3.66 s. Which means, It takes 3.66 seconds for the red car to meet up with the blue car.

From the previous part, we were able to confirm that it took 3.66 seconds for the red car to meet up the blue car. Also, the speed with which it were traveling was travelling at, was constant, so we only need to multiply it by the time from (1) to get the distance.

v = d * t = 34 * 3.66 = 124.4

Therefore the red car travels at 124.4 m before catching up to the blue car.

If the red car starts to accelerate the moment we see it, the time it will take, to get to the blue car will be less than what we had gotten. We can find this using one of the equations of motion.

S = ut + ½gt², where

S = 22

u = 6

t = ?

g = 2/3

22 = 6t + 1/3t²

By using the quadratic formula, we find out the two answers listed below

t1 = 3.12 s

t2 = - 21.12 s

We all know that negative time is not possible, so the answer is t1. At 3.12 seconds

8 0

3 years ago

Two identical closely spaced circular disks form a parallel-plate capacitor. Transferring 1.4×109 electrons from one disk to the

allsm [11]

Answer:

r = 6.5*10^-3 m

Explanation:

I'm assuming you meant to ask the diameters of the disk, if so, here's it

Given

Quantity of charge on electron, Q = 1.4*10^9

Electric field strength, e = 1.9*10^5

q = Q * 1.6*10^-19

q = 2.24*10^-10

E = q/ε(0)A, making A the subject of formula, we have

A = q / [E * ε(0)], where

ε(0) = 8.85*10^-12

A = 2.24*10^-10 / (1.9*10^5 * 8.85*10^-12)

A = 2.24*10^-10 / 1.6815*10^-6

A = 1.33*10^-4 m²

Remember A = πr²

1.33*10^-4 = 3.142 * r²

r² = 1.33*10^-4 / 3.142

r² = 4.23*10^-5

r = 6.5*10^-3 m

3 0

3 years ago

A rubbit gets down from a rump which its /\x=0.85m in 0.5s, The rubbit's mass is 2kg, what is the net Force?

Ira Lisetskai [31]

Answer: 13.6 N

Explanation:

The equation of motion for the rabbit is:

$\Delta x=V_{ox}t+\frac{1}{2}a_{x}t^{2}$ (1)

Where:

$\Delta x=0.85 m$ is the distance traveled by the rabbit

$V_{ox}=0 m/s$ is the rabbit's initial velocity, assuming it started from rest

$t=0.5 s$ is the time

$a_{x}$ is the acceleration

Isolating $a_{x}$ :

$a_{x}=\frac{2 \Delta x}{t^{2}}$ (2)

$a_{x}=\frac{2 (0.85 m)}{(0.5)^{2}}$ (3)

$a_{x}=6.8 m/s^{2}$ (4)

On the other hand, the force $F_{x}$ is given by:

$F_{x}=m.a_{x}$ (5)

Where $m=2 kg$ is the mass of the rabbit

Substituting (4) in (5):

$F_{x}=(2 kg)(6.8 m/s^{2})$ (6)

Finally:

$F_{x}=13.6 N$

6 0

3 years ago

PLS HELP. A flatbed car of a train moves 8 m/s to the east. A jogger runs along to top the flatbed car (which is not very safe)

jonny [76]

Answer:

2 m/s

Explanation: Given that a flatbed car of a train moves 8 m/s to the east. A jogger runs along to top the flatbed car (which is not very safe) with a velocity of 6 m/s to the west.

Since the jogger is moving in an opposite direction to the direction of the train, and velocity is the distance covered in a specific direction, the jogger will be moving at a velocity relative to the velocity of the train.

Velocity = (8 - 6) m/s

Velocity = 2 m/s

Therefore, the jogger will be moving at the speed of 2 m/s

5 0
