Water falls without splashing at a rate of 0.370 l/s from a height of 2.90 m into a 0.690-kg bucket on a scale. if the bucket is

raketka [301]

<span>R = rate of flow = 0.370 L/s H = height = 2.9 m T= time = 3.9 s V = velocity of water when it hits the bucket = sqrt(2gh) = sqrt(2 x 9.8 x 2.9) =7.539 m/s2 G value = 9.8 m/s2 Wb = weight of bucket = 0.690 kg x 9.8 m/s2 = 6.762 N Wa = weight of accumulated water after 3.9 s Fi = force of impact of water on the bucket S = reading on the scale = Wa + Wb + Fi mass of water accumulated after 3.9 s = R x T = 0.370 x 3.9 = 1.443 L = 1.443 kg Therefore, Wa = 1.443 x 9.8 = 14.1414 N Fi = rate of change of momentum at the impact point = R x V (because R = dm/dt) = 0.37 x 7.539 = 2.78943 N S = 14.1414 + 6.762 + 2.78943 = 23.692 N</span>

8 0

3 years ago

Calculate the kinetic energy of a moving 4 kg object traveling at a velocity of 3 m/a

Alina [70]

Answer:

Explanation:KE = 18 J

7 0

3 years ago

A closely wound search coil has an area of 3.21 cm2, 120 turns, and a resistance of 58.7 O. It is connected to a charge-measurin

Alexxx [7]

Answer:

The magnetic field in the System is 0.095T

Explanation:

To solve the exercise it is necessary to use the concepts related to Faraday's Law, magnetic flux and ohm's law.

By Faraday's law we know that

$\epsilon = \frac{NBA}{t}$

Where,

$\epsilon =$ electromotive force

N = Number of loops

B = Magnetic field

A = Area

t= Time

For Ohm's law we now that,

V = IR

Where,

I = Current

R = Resistance

V = Voltage (Same that the electromotive force at this case)

In this system we have that the resistance in series of coil and charge measuring device is given by,

$R = R_c + R_d$

And that the current can be expressed as function of charge and time, then

$I = \frac{q}{t}$

Equation Faraday's law and Ohm's law we have,

$V = \epsilon$

$IR = \frac{NBA}{t}$

$(\frac{q}{t})(R_c+R_d) = \frac{NBA}{t}$

Re-arrange for Magnetic Field B, we have

$B = \frac{q(R_c+R_d)}{NA}$

Our values are given as,

$R_c = 58.7\Omega$

$R_d = 45.5\Omega$

$N = 120$

$q = 3.53*10^{-5}C$

$A = 3.21cm^2 = 3.21*10^{-4}m^2$

Replacing,

$B = \frac{(3.53*10^{-5})(58.7+45.5)}{120*3.21*10^{-4}}$

$B = 0.095T$

Therefore the magnetic field in the System is 0.095T

3 0

3 years ago

An electron moving parallel to a uniform electric field increases its speed from 2.0 × 107 m/s to 4.0 × 107 m/s over a distance

jeka94

Answer:

$1.8\times 105 N/C$

Explanation:

We are given that

$u=2\times 10^7 m/s$

$v=4\times 10^7 m/s$

d=1.9 cm= $\frac{1.9}{100}=0.019 m$

Using 1m=100 cm

We have to find the electric field strength.

$v^2-u^2=2as$

Using the formula

$(4\times 10^7)^2-(2\times 10^7)^2=2a(0.019)$

$16\times 10^{14}-4\times 10^{14}=0.038a$

$0.038a=12\times 10^{14}$

$a=\frac{12}{0.038}\times 10^{14}=3.16\times 10^{16}m/s^2$

$q=1.6\times 10^{-19} C$

Mass of electron,m $=9.1\times 10^{-31} kg$

$E=\frac{ma}{q}$

Substitute the values

$E=\frac{9.1\times 10^{-31}\times 3.16\times 10^{16}}{1.6\times 10^{-19}}$

$E=1.8\times 105 N/C$

7 0

4 years ago

A ball is dropped from the top of the building.it initially moves at 4.0 m/s after 0.5 seconds it moves at 3.8m/s what force is

Ivahew [28]

The correct answer is

Air resistance

In fact, when a ball is in free fall, there are two forces acting on it:

- its weight (force of gravity), acting downward

- the air resistance, acting upward

The effect of the weight is to accelerate the ball, because its direction is the same as the direction of motion of the ball, while the effect of the air resistance is to slow down the ball, because its direction is opposite to that of the motion.

6 0

3 years ago
