What does the slope on a velocity-time graph measure?

2 answers:

6 0

Answer:The slope in the velocity-time graph represents the acceleration. The slope is defined as the ratio of change in y-axis to change in the x-axis. The slope is represented by the letter m and following is the general formula used for determining the slope:

Explanation:

blagie [28]3 years ago

3 0

The slope of a velocity graph represents the acceleration of the object. So, the value of the slope at a particular time represents the acceleration of the object at that instant.

is that what it’s asking?

You might be interested in

The scientist to first introduce the concept of inertia was

skelet666 [1.2K]

The first scientist to introduce the concept of inertia was Galileo

4 0

3 years ago

Calculate the electric field at the center of a square

pantera1 [17]

Answer:

$E_y=1175510.2\ N.C^{-1}$

The Magnitude of electric field is in the upward direction as shown directly towards the charge $q_1$ .

Explanation:

Given:

side of a square, $a=52.5\ cm$

charge on one corner of the square, $q_1=+45\times 10^{-6}\ C$

charge on the remaining 3 corners of the square, $q_2=q_3=q_4=-27\times 10^{-6}\ C$

Distance of the center from each corners $=\frac{1}{2} \times diagonals$

$diagonal=\sqrt{52.5^2+52.5^2}$

$diagonal=74.25\cm=0.7425\ m$

∴Distance of center from corners, $b=0.3712\ m$

Now, electric field due to charges is given as:

$E=\frac{1}{4\pi\epsilon_0}\times \frac{q}{b^2}$

For charge $q_1$ we have the field lines emerging out of the charge since it is positively charged:

$E_1=9\times 10^9\times \frac{45\times 10^{-6}}{0.3712^2}$

$E_1=2938775.5\ N.C^{-1}$

Force by each of the charges at the remaining corners:

$E_2=E_3=E_4=9\times 10^9\times \frac{27\times 10^{-6}}{0.3712^2}$

$E_2=E_3=E_4=1763265.3\ N.C^{-1}$

Now, net electric field in the vertical direction:

$E_y=E_1-E_4$

$E_y=1175510.2\ N.C^{-1}$

Now, net electric field in the horizontal direction:

$E_y=E_2-E_3$

$E_y=0\ N.C^{-1}$

So the Magnitude of electric field is in the upward direction as shown directly towards the charge $q_1$ .

8 0

3 years ago

Being able to see a square in the middle of the image despite not having lines to form a square represents the Gestalt principle

vredina [299]

Answer: The correct answer for the blank is -

C. closure.

Gestalt principle of closure describes how we perceive complete figures even when the information that form the figure is missing.

This is due the fact that our brain responds to the familiar patterns inspite of getting incomplete information.

For instance, in the given question, we are able to perceive an image of square in the center despite not having actual lines that form a square.

Thus, it represents principle of closure.

7 0

3 years ago

Read 2 more answers

What is the weight of a 1-kilogram brick resting on a table?

MakcuM [25]

Answer:

The weight if the block is 10Newtons

Explanation:

The weight of any object is quantity of matter the object contains and it is always acting downwards on such body. This shows that the object is under the influence of gravity.

The weight of an object is calculated as mass of the object × its acceleration due to gravity

W = mg

Give the mass of the brick to be 1kg

g is the acceleration due to gravity = 10m/s²

Weight of the object = 1 × 10

= 10kgm/s² or 10Newtons

5 0

3 years ago

A radio wave wavelength is shorter than visible light. True or False.

Dovator [93]

False. Radio waves have much longer wavelengths and lower frequencies than visible light waves

6 0

3 years ago

Read 2 more answers
