Answer:
the force conveyed by the fibers is 947.93 lb-f
Explanation:
Given the data in the question;
V_f = 80% = 0.8
V_m = 1 - V_f = 1 - 0.8 = 0.2
Now,
length of fibre L_f = length of Nylon L_n
V_f = A_f × L_f = 0.8
V_m = A_n × L_n = 0.2
so
V_f/V_m = A_f/A_n = 0.8/0.2
A_f/A_n = 4
now, the strains in fibre is equal to strains in nylon
(P/AE)f = (P/AE)n
P_f/A_fE_f = P_n/A_nE_n
P_f = (A_f/A_n)(E_f/E_n)(P_n)
P_f = ( 4 )( 131 / 2.8 )(Pn)
P_f = 187.14Pn
and P_n = Pf / 187.14
Hence
given that P_total = 953 lb-f
P_f + P_n = 953
P_f + ( P_f / 187.14 ) = 953
P_f( 1 + ( 1 / 187.14 ) ) = 953
P_f( 1.00534359 = 953
P_f = 953 / 1.00534359
P_f = 947.93 lb-f
Therefore, the force conveyed by the fibers is 947.93 lb-f
Answer:
Yes this claim is correct.
Explanation:
The shear stress at any point is proportional to the velocity gradient at any that point. Since the fluid that is in contact with the pipe wall shall have zero velocity due to no flow boundary condition and if we move small distance away from the wall the velocity will have a non zero value thus a maximum gradient will exist at the surface of the pipe hence correspondingly the shear stresses will also be maximum.
Answer:
Power required to drive the escalator shall be equal to the rate at which the energies of the persons is increased.

As we infer from the above equation If the velocity of the escalator is doubled then the Power required will also be doubled and become 31.215kW
Answer:
A.) 1mv = 2000N
B.) Impulse = 60Ns
C.) Acceleration = 66.67 m/s^2
Velocity = 4 m/s
Displacement = 0.075 metre
Absorbed energy = 60 J
Explanation:
A.) Using a mathematical linear equation,
Y = MX + C
Where M = (2000 - 0)/( 898 - 0 )
M = 2000/898
M = 2.23
Let Y = 2000 and X = 898
2000 = 2.23(898) + C
2000 = 2000 + C
C = 0
We can therefore conclude that
1 mV = 2000N
B.) Impulse is the product of force and time.
Also, impulse = momentum
Given that
Mass M = 30kg
Velocity V = 2 m/s
Impulse = M × V = momentum
Impulse = 30 × 2 = 60 Ns
C.) Force = mass × acceleration
F = ma
Substitute force and mass into the formula
2000 = 30a
Make a the subject of formula
a = 2000/30
acceleration a = 66.67 m/s^2
Since impulse = 60 Ns
From Newton 2nd law,
Force = rate of change in momentum
Where
change in momentum = -MV - (- MU)
Impulse = -MV + MU
Where U = initial velocity
60 = -60 + MU
30U = 120
U = 120/30
U = 4 m/s
Force = 2000N
Impulse = Ft
Substitute force and impulse to get time
60 = 2000t
t = 60/2000
t = 0.03 second
Using third equation of motion
V^2 = U^2 + 2as
Where S = displacement
4^2 = 2^2 + 2 × 66.67S
16 = 4 + 133.4S
133.4S = 10
S = 10/133.4
S = 0.075 metre
D.) Energy = 1/2 mV^2
Energy = 0.5 × 30 × 2^2
Energy = 15 × 4 = 60J
