Answer:
a) V = 0.354
b) G = 25.34 GPA
Explanation:
Solution:
We first determine Modulus of Elasticity and Modulus of rigidity
Elongation of rod ΔL = 1.4 mm
Normal stress, δ = P/A
Where P = Force acting on the cross-section
A = Area of the cross-section
Using Area, A = π/4 · d²
= π/4 · (0.0020)² = 3.14 × 10⁻⁴m²
δ = 50/3.14 × 10⁻⁴ = 159.155 MPA
E(long) = Δl/l = 1.4/600 = 2.33 × 10⁻³mm/mm
Modulus of Elasticity Е = δ/ε
= 159.155 × 10⁶/2.33 × 10⁻³ = 68.306 GPA
Also final diameter d(f) = 19.9837 mm
Initial diameter d(i) = 20 mm
Poisson said that V = Е(elasticity)/Е(long)
= - <u>( 19.9837 - 20 /20)</u>
2.33 × 10⁻³
= 0.354,
∴ v = 0.354
Also G = Е/2. (1+V)
= 68.306 × 10⁹/ 2.(1+ 0.354)
= 25.34 GPA
⇒ G = 25.34 GPA
Answer:
A) Their creations change society.
Answer:
5.6 mm
Explanation:
Given that:
A cylindrical tank is required to contain a:
Gage Pressure P = 560 kPa
Allowable normal stress = 150 MPa = 150000 Kpa.
The inner diameter of the tank = 3 m
In a closed cylinder there exist both the circumferential stress and the longitudinal stress.
Circumferential stress
Making thickness t the subject; we have
t = 0.0056 m
t = 5.6 mm
For longitudinal stress.
t = 0.0028 mm
t = 2.8 mm
From the above circumferential stress and longitudinal stress; the stress with the higher value will be considered ; which is circumferential stress and it's minimum value with the maximum thickness = 5.6 mm
i believe the correct answer is c but i’m sorry if i’m not correct
