1)

Steam flows steadily through an adiabatic turbine. The inlet conditions of the steam are 10 MPa, 450°C, and 80 m/s, and the exit

8090 [49]

Answer:

a) The change in Kinetic energy, KE = -1.95 kJ

b) Power output, W = 10221.72 kW

c) Turbine inlet area, $A_1 = 0.0044 m^2$

Explanation:

a) Change in Kinetic Energy

For an adiabatic steady state flow of steam:

$KE = \frac{V_2^2 - V_1^2}{2} \\$ .........(1)

Where Inlet velocity, V₁ = 80 m/s

Outlet velocity, V₂ = 50 m/s

Substitute these values into equation (1)

$KE = \frac{50^2 - 80^2}{2} \\$

KE = -1950 m²/s²

To convert this to kJ/kg, divide by 1000

KE = -1950/1000

KE = -1.95 kJ/kg

b) The power output, w

The equation below is used to represent a steady state flow.

$q - w = h_2 - h_1 + KE + g(z_2 - z_1)$

For an adiabatic process, the rate of heat transfer, q = 0

z₂ = z₁

The equation thus reduces to :

w = h₁ - h₂ - KE...........(2)

Where Power output, $W = \dot{m}w$ ..........(3)

Mass flow rate, $\dot{m} = 12 kg/s$

To get the specific enthalpy at the inlet, h₁

At P₁ = 10 MPa, T₁ = 450°C,

h₁ = 3242.4 kJ/kg,

Specific volume, v₁ = 0.029782 m³/kg

At P₂ = 10 kPa, $h_f = 191.81 kJ/kg, h_{fg} = 2392.1 kJ/kg$ , x₂ = 0.92

specific enthalpy at the outlet, h₂ = $h_1 + x_2 h_{fg}$

h₂ = 3242.4 + 0.92(2392.1)

h₂ = 2392.54 kJ/kg

Substitute these values into equation (2)

w = 3242.4 - 2392.54 - (-1.95)

w = 851.81 kJ/kg

To get the power output, put the value of w into equation (3)

W = 12 * 851.81

W = 10221.72 kW

c) The turbine inlet area

$A_1V_1 = \dot{m}v_1\\\\A_1 * 80 = 12 * 0.029782\\\\80A_1 = 0.357\\\\A_1 = 0.357/80\\\\A_1 = 0.0044 m^2$

3 0

3 years ago

On a piece of paper, sketch the x-y stress state and the properly oriented principal stress state. Use the resulting sketch to a

stealth61 [152]

Answer:

See explaination

Explanation:

Please kindly check attachment for the step by step and very detailed solution of the given problem

6 0

3 years ago

Technician A says that a voltage drop of 0.8 volts on the starter ground circuit is within specifications. Technician B says tha

Romashka-Z-Leto [24]

Answer:

Technician A is wrong

Technician B is right

Explanation:

voltage drop of 0.8 volts on the starter ground circuit is not within specifications. Voltage drop should be within the range of 0.2 V to 0.6 V but not more than that.

A spun bearing can seize itself around the crankshaft journal causing it not to move. As the car ignition system is turned on, the stater may draw high current in order to counter this seizure.

8 0

3 years ago

You find an unnamed fluid in the lab we will call Fluid A. Fluid A has a specific gravity of 1.65 and a dynamic viscosity of 210

Naily [24]

Answer:

1.2727 stokes

Explanation:

specific gravity of fluid A = 1.65

Dynamic viscosity = 210 centipoise

<u>Calculate the kinematic viscosity of Fluid A </u>

First step : determine the density of fluid A

Pa = Pw * Specific gravity = 1000 * 1.65 = 1650 kg/m^3

next : convert dynamic viscosity to kg/m-s

210 centipoise = 0.21 kg/m-s

Kinetic viscosity of Fluid A = dynamic viscosity / density of fluid A

= 0.21 / 1650 = 1.2727 * 10^-4 m^2/sec

Convert to stokes = 1.2727 stokes

4 0

3 years ago

What is the metal removal rate when a 2 in-diameter hole 3.5 in deep is drilled in 1020 steel at cutting speed of 120 fpm with a

Studentka2010 [4]

Answer:

a) the metal removal rate is 14.4 in³/min

b) the cutting time is 0.98 min

Explanation:

Given the data from the question

first we find the rpm for the spindle of the drilling tool, using the equation

Ns = 12V/πD

V is the cutting speed(120 fpm) and D is the diameter of the hole( 2 in)

so we substitute

Ns = 12 × 120 / π2

Ns = 1440 / 6.2831

Ns = 229.18 rmp

Now we find the metal removal rate using the equation

MRR = (πD²/4) Fr × Ns

Fr is the feed rate( 0.02 ipr ),

so we substitute

MRR = ((π × 2²)/4) × 0.02 × 229.18

MRR = 14.3998 ≈ 14.4 in³/min

Therefore the metal removal rate is 14.4 in³/min

Next we find the allowance for approach of the tip of the drill

A = D/2

A = 2/2

= 1 in

now find the time required to drill the hole

Tm = (L + A) / (Fr × Ns)

Lis the the depth of the hole( 3.5 in)

so we substitute our values

Tm = (3.5 + 1) / (0.02 × 229.18 )

Tm = 4.5 / 4.5836

Tm = 0.98 min

Therefore the cutting time is 0.98 min
