Foam weather stripping is often placed in the frames of doors and

Water flows around a 6-ft diameter bridge pier with a velocity of 12 ft/s. Estimate the force (per unit length) that the water e

jolli1 [7]

Answer: hello the diagram related to your question is missing please the third image is the missing part of the question

Fx = 977.76 Ib/ft

Explanation:

Estimate the force that water exerts on the pier

V = 12 ft/s

D( diameter ) = 6 ft

first express the force on the first half of the cylinder as

Fx1 = - $-2\int\limits^\pi _\frac{\pi }{2} {Ps*cos\beta *a} \, d\beta$ ---------------- ( 1 )

where ; Fy = 0

Ps = Po + 1/2 Pv^2 ( 1 - 4 sin^2β ) ------------- ( 2 )

Input equation (2) into equation ( 1 ) (note : assuming Po = 0 )

attached below is the remaining part of the solution

3 0

3 years ago

A transformer has 300,000 windings in its primary coil and uses 12,000V AC input. (4 points) How many windings would be needed t

viva [34]

Answer:

2750

Explanation:

The number of windings and the voltage are proportional.

__

Let n represent the number of windings to produce 110 Vac. Then the proportion is ...

n/110 = 300,000/12,000

n = 110(300/12) = 2750 . . . . multiply by 110

2750 windings would be needed to produce 110 Vac at the output.

7 0

2 years ago

I have a stream with three components, A, B, and C, coming from another process. The stream is 50 % A, and the balance is equal

tigry1 [53]

Answer:

$X_{A} = \frac{N_{Ao}-N_{A}}{N_{Ao}}$

Nₐ₀-Nₐ = 1.33

Nₐ₀ = 2.5

Conversion X = 1.33/2.5 = 0.533

Explanation:

A + 2B + 4C ⇒ 2X + 3Y

Given a stream containing 50% A, 25% B and 25% C, to get the limiting reactant, lets take a simple basis

Say stream is 10 moles, this give

A = 5moles

B = 2.5mole

C = 2.5moles

from the balanced equation above,

1mole of A ⇒ 4moles of C

∴ 5moles of A ⇒ (5x4)/1 ⇒ 20moles of C

also;

2mole of B ⇒ 4moles of C

∴ 2.5moles of B ⇒ (2.5x4)/2 ⇒ 5moles of C

so clearly from above reactant C is the limiting reactant.

Note: To get conversion of a process, we must use the limiting reactant. this is because ones it is used up, the reaction comes to an end

Formula to obtain conversion is:

Conversion = (Amount of A used up)/(Amount of A fed into the system)

$X_{A} = \frac{N_{Ao}-N_{A}}{N_{Ao}}$

where, Nₐ₀-Nₐ = is the amount in moles of A used up

Nₐ₀ = amount in moles of A fed into the system

The next question is what mole of reactant C will give 0.1mole fraction of Y

Recall our basis = 10moles

from conservation of mass law, 10mole of product must come out which 0.1 moles fraction is Y

therefore amount Y in the product is = 0.1x10 = 1mole

if 3moles of Y ⇒ 4mole of C

∴ 1mole of Y ⇒ (1x4)/3 ⇒ 1.33moles of C

calculating the conversion of limiting reactant C that will give 0.1mole fraction of Y

Nₐ₀-Nₐ = 1.33

Nₐ₀ = 2.5

Conversion X = 1.33/2.5 = 0.533

5 0

3 years ago

What are the BENEFITS and RISKS of using automobiles?

Molodets [167]

Answer:

u could get hurt or it could not sence in but it easy to work with and u can just relax till u get were ur going.

Explanation:

3 0

3 years ago

A large heat pump should upgrade 5 MW of heat at 85°C to be delivered as heat at 150°C. Suppose the actual heat pump has a COP o

AysviL [449]

Answer:

W=2 MW

Explanation:

Given that

COP= 2.5

Heat extracted from 85°C

Qa= 5 MW

Lets heat supplied at 150°C = Qr

The power input to heat pump = W

From first law of thermodynamics

Qr= Qa+ W

We know that COP of heat pump given as

$COP=\dfrac{Qr}{W}$

$2.5=\dfrac{5}{W}$

W=2 MW

For Carnot heat pump

$COP=\dfrac{T_2}{T_2-T_1}$

$2.5=\dfrac{T_2}{T_2-(273+85)}$

2.5 T₂ - 895= T₂

T₂=596.66 K

T₂=323.6 °C

7 0

3 years ago
