Please. my brain isn’t working right now

A hot brass plate is having its upper surface cooled by impinging jet of air at temperature of 15°C and convection heat transfer

gulaghasi [49]

Answer:

809.98°C

Explanation:

STEP ONE: The first step to take in order to solve this particular Question or problem is to find or determine the Biot value.

Biot value = (heat transfer coefficient × length) ÷ thermal conductivity.

Biot value = (220 × 0.1)÷ 110 = 0.2.

Biot value = 0.2.

STEP TWO: Determine the Fourier number. Since the Biot value is greater than 0.1. Tis can be done by making use of the formula below;

Fourier number = thermal diffusivity × time ÷ (length)^2.

Fourier number = (3 × 60 × 33.9 × 10^-6)/( 0.1)^2 = 0.6102.

STEP THREE: This is the last step for the question, here we will be calculating the temperature of the center plane of the brass plate after 3 minutes.

Thus, the temperature of the center plane of the brass plane after 3 minutes = (1.00705) (0.89199) (900- 15) + 15.

= > the temperature of the center plane of the brass plane after 3 minutes = 809.98°C.

5 0

3 years ago

Which examples demonstrate tasks commonly performed in Maintenance/Operations jobs? Check all that apply.

Verdich [7]

1.Ross fixes a dishwasher for a homeowner.

3.Cassandra fixes holes in an old road.

4 0

3 years ago

Read 2 more answers

Refrigerant 134a enters the evaporator of a refrigeration system operating at steady state at -16oC and a quality of 20% at a ve

Dmitry [639]

Answer:

mass flow rate = 0.0534 kg/sec

velocity at exit = 29.34 m/sec

Explanation:

From the information given:

Inlet:

Temperature $T_1 = -16^0\ C$

Quality $x_1 = 0.2$

Outlet:

Temperature $T_2 = -16^0 C$

Quality $x_2 = 1$

The following data were obtained at saturation properties of R134a at the temperature of -16° C

$v_f= 0.7428 \times 10^{-3} \ m^3/kg \\ \\ v_g = 0.1247 \ m^3 /kg$

$v_1 = v_f + x_1 ( vg - ( v_f)) \\ \\ v_1 = 0.7428 \times 10^{-3} + 0.2 (0.1247 -(0.7428 \times 10^{-3})) \\ \\ v_1 = 0.0255 \ m^3/kg \\ \\ \\ v_2 = v_g = 0.1247 \ m^3/kg$

$m = \rho_1A_1v_1 = \rho_2A_2v_2 \\ \\ m = \dfrac{1}{0.0255} \times \dfrac{\pi}{4}\times (1.7 \times 10^{-2})^2\times 6 \\ \\ \mathbf{m = 0.0534 \ kg/sec}$

$\rho_1A_1v_1 = \rho_2A_2v_2 \\ \\ A_1 =A_2 \\ \\ \rho_1v_1 = \rho_2v_2 \\ \\ \implies \dfrac{1}{0.0255} \times6 = \dfrac{1}{0.1247}\times (v_2)\\ \\ \\\mathbf{\\ v_2 = 29.34 \ m/sec}$

3 0

3 years ago

(3) Calculate the heat flux through a sheet of brass 7.5 mm (0.30 in.) thick if the temperatures at the two faces are 150°Cand 5

bezimeni [28]

Answer:

a.) 1.453MW/m2, b.) 2,477,933.33 BTU/hr c.) 22,733.33 BTU/hr d.) 1,238,966.67 BTU/hr

Explanation:

Heat flux is the rate at which thermal (heat) energy is transferred per unit surface area. It is measured in W/m2

Heat transfer(loss or gain) is unit of energy per unit time. It is measured in W or BTU/hr

1W = 3.41 BTU/hr

Given parameters:

thickness, t = 7.5mm = 7.5/1000 = 0.0075m

Temperatures 150 C = 150 + 273 = 423 K

50 C = 50 + 273 = 323 K

Temperature difference, T = 423 - 323 = 100 K

We are assuming steady heat flow;

a.) Heat flux, Q" = kT/t

K= thermal conductivity of the material

The thermal conductivity of brass, k = 109.0 W/m.K

Heat flux, $Q" = \frac{109 * 100}{0.0075} = 1,453,333.33 W/m^{2} \\ Heat flux, Q" = 1.453MW/m^{2} \\$

b.) Area of sheet, A = 0.5m2

Heat loss, Q = kAT/t

Heat loss, $Q = \frac{109*0.5*100}{0.0075} = 726,666.667W$

Heat loss, Q = 726,666.667 * 3.41 = 2,477,933.33 BTU/hr

c.) Material is now given as soda lime glass.

Thermal conductivity of soda lime glass, k is approximately 1W/m.K

Heat loss, $Q=\frac{1*0.5*100}{0.0075} = 6,666.67W$

Heat loss, Q = 6,666.67 * 3.41 = 22,733.33 BTU/hr

d.) Thickness, t is given as 15mm = 15/1000 = 0.015m

Heat loss, $Q=\frac{109*0.5*100}{0.015} =363,333.33W$

Heat loss, Q = 363,333.33 * 3.41 = 1,238,966.67 BTU/hr

5 0

3 years ago

Student A says hazardous waste can take the form of solid, liquid, or gas. Student B says hazardous waste can only take the form

lina2011 [118]

Answer:

Student A

Explanation:

hope this helps have a great day

4 0

3 years ago
