Some people will realize that they are dreaming while the dream is happening. this is called

) Water flows through a horizontal coil heated from the outside by high-temperature flue gases. As it passes through the coil th

Mademuasel [1]

Explanation:

Formula for steady flow energy equation for the flow of fluid is as follows.

$m[h_{1} + \frac{V^{2}_{1}}{2}] + z_{1}g] + q = m[h_{1} + \frac{V^{2}_{1}}{2} + z_{1}g] + w$

Now, we will substitute 0 for both $z_{1}$ and $z_{2}$ , 0 for w, 334.9 kJ/kg for $h_{1}$ , 2726.5 kJ/kg for $h_{2}$ , 5 m/s for $V_{1}$ and 220 m/s for $V_{2}$ .

Putting the given values into the above formula as follows.

$m[h_{1} + \frac{V^{2}_{1}}{2}] + z_{1}g] + q = m[h_{1} + \frac{V^{2}_{1}}{2} + z_{1}g] + w$

$1 \times [334.9 \times 10^{3} J/kg + \frac{(5 m/s)^{2}}{2} + 0] + q = 1 \times [2726.5 \times 10^{3} + \frac{(220 m/s)^{2}}{2} + 0] + 0$

q = 6597.711 kJ

Thus, we can conclude that heat transferred through the coil per unit mass of water is 6597.711 kJ.

6 0

4 years ago

8. An unpowered flywheel is slowed by a constant frictional torque. At time t = 0 it has an angular velocity of 200 rad/s. Ten s

allsm [11]

Answer:

a) $\omega = 50\,\frac{rad}{s}$ , b) $\omega = 0\,\frac{rad}{s}$

Explanation:

The magnitude of torque is a form of moment, that is, a product of force and lever arm (distance), and force is the product of mass and acceleration for rotating systems with constant mass. That is:

$\tau = F \cdot r$

$\tau = m\cdot a \cdot r$

$\tau = m \cdot \alpha \cdot r^{2}$

Where $\alpha$ is the angular acceleration, which is constant as torque is constant. Angular deceleration experimented by the unpowered flywheel is:

$\alpha = \frac{170\,\frac{rad}{s} - 200\,\frac{rad}{s} }{10\,s}$

$\alpha = -3\,\frac{rad}{s^{2}}$

Now, angular velocities of the unpowered flywheel at 50 seconds and 100 seconds are, respectively:

a) t = 50 s.

$\omega = 200\,\frac{rad}{s} - \left(3\,\frac{rad}{s^{2}} \right) \cdot (50\,s)$

$\omega = 50\,\frac{rad}{s}$

b) t = 100 s.

Given that friction is of reactive nature. Frictional torque works on the unpowered flywheel until angular velocity is reduced to zero, whose instant is:

$t = \frac{0\,\frac{rad}{s}-200\,\frac{rad}{s} }{\left(-3\,\frac{rad}{s^{2}} \right)}$
