The u.s has sent unmanned spacecrafts to ___ the planets in our solar system

If the angle of refraction is 20 degrees what is the angle of incidence

Romashka-Z-Leto [24]

Answer:

13.1

Explanation:

that's what I'm gonna go with, but u can research more

5 0

2 years ago

Two resistors of 15 and 30 ω are connected in parallel. if the combination is connected in series with a 9. 0-v battery and a 20

Stels [109]

Resistors Working Together.

Resistors are shown coupled in parallel to a voltage source in Figure 10.3.4. When all of the resistors' ends are connected to one another by a continuous wire of minimal resistance and their other ends are also connected to one another by a continuous wire of minimal resistance, the resistors are said to be in parallel. There is a constant potential drop across all resistors. Ohm's law, I=V/R, can be used to determine the current flowing through each resistor while the voltage is constant across each resistor. For instance, the headlights, radio, and other components of an automobile are linked in parallel so that each subsystem can use the entire voltage of the source and function independently. The wiring in your home or any other structure shares the same

The original circuit is shown in part a with two parallel resistors linked to a voltage source, and the equivalent circuit is shown in part b with one equivalent resistor connected to the voltage source.

learn more about resistors brainly.com/question/22259983

#4159

3 0

1 year ago

A 70.0 kg astronaut is training for accelerations that he will experience upon reentry. He is placed in a centrifuge (r = 15.0 m

Levart [38]

Answer:

1.3823 rad/s

20.7345 m/s

28.66129935 m/s²

$a=2.92164g$

2006.29095 N radially outward

Explanation:

r = Radius = 15 m

m = Mass of person = 70 kg

g = Acceleration due to gravity = 9.81 m/s²

Angular velocity is given by

$\omega=13.2\times \dfrac{2\pi}{60}\\\Rightarrow \omega=1.3823\ rad/s$

Angular velocity is 1.3823 rad/s

Linear velocity is given by

$v=r\omega\\\Rightarrow v=15\times 1.3823\\\Rightarrow v=20.7345\ m/s$

The linear velocity is 20.7345 m/s

Centripetal acceleration is given by

$a_c=r\omega^2\\\Rightarrow a_c=15\times 1.3823^2\\\Rightarrow a_c=28.66129935\ m/s^2$

The centripetal acceleration is 28.66129935 m/s²

Acceleration in terms of g

$\dfrac{a}{g}=\dfrac{28.66129935}{9.81}\\\Rightarrow a=2.92164g$

$a=2.92164g$

Centripetal force is given by

$F_c=ma_c\\\Rightarrow F_c=70\times 28.66129935\\\Rightarrow F_c=2006.29095\ N$

The centripetal force is 2006.29095 N radially outward

The torque will be experienced when the centrifuge is speeding up of slowing down i.e., when it is accelerating and decelerating.

3 0

3 years ago

A ball is tossed with enough speed straight up so that it is in the air several seconds. (a) What is the velocity of the ball wh

irina1246 [14]

(a) Zero

When the ball reaches its highest point, the direction of motion of the ball reverses (from upward to downward). This means that the velocity is changing sign: this also means that at that moment, the velocity must be zero.

This can be also understood in terms of conservation of energy: when the ball is tossed up, initially it has kinetic energy

$K=\frac{1}{2}mv^2$

where m is the ball's mass and v is the initial speed. As it goes up, this kinetic energy is converted into potential energy, and when the ball reaches the highest point, all the kinetic energy has been converted into potential energy:

$U=mgh$

where g is the gravitational acceleration and h is the height of the ball at highest point. At that point, therefore, the potential energy is maximum, while the kinetic energy is zero, and so the velocity is also zero.

(b) 9.8 m/s upward

We can find the velocity of the ball 1 s before reaching its highest point by using the equation:

$a=\frac{v-u}{t}$

where

a = g = -9.8 m/s^2 is the acceleration due to gravity, which is negative since it points downward

v = 0 is the final velocity (at the highest point)

u is the initial velocity

t = 1 s is the time interval

Solving for u, we find

$u=v-at = 0 -(-9.8 m/s^2)(1 s)= +9.8 m/s$

and the positive sign means it points upward.

(c) -9.8 m/s

The change in velocity during the 1-s interval is given by

$\Delta v = v -u$

where

v = 0 is the final velocity (at the highest point)

u = 9.8 m/s is the initial velocity

Substituting, we find

$\Delta v = 0 - (+9.8 m/s)=-9.8 m/s$

(d) 9.8 m/s downward

We can find the velocity of the ball 1 s after reaching its highest point by using again the equation:

$a=\frac{v-u}{t}$

where this time we have

a = g = -9.8 m/s^2 is the acceleration due to gravity, still negative

v is the final velocity (1 s after reaching the highest point)

u = 0 is the initial velocity (at the highest point)

t = 1 s is the time interval

Solving for v, we find

$v = u+at = 0 +(-9.8 m/s^2)(1 s)= -9.8 m/s$

and the negative sign means it points downward.

(e) -9.8 m/s

The change in velocity during the 1-s interval is given by

$\Delta v = v -u$

where here we have

v = -9.8 m/s is the final velocity (1 s after reaching the highest point)

u = 0 is the initial velocity (at the highest point)

Substituting, we find

$\Delta v = -9.8 m/s - 0=-9.8 m/s$

(f) -19.6 m/s

The change in velocity during the overall 2-s interval is given by

$\Delta v = v -u$

where in this case we have:

v = -9.8 m/s is the final velocity (1 s after reaching the highest point)

u = +9.8 m/s is the initial velocity (1 s before reaching the highest point)

Substituting, we find

$\Delta v = -9.8 m/s - (+9.8 m/s)=-19.6 m/s$

(g) -9.8 m/s^2

There is always one force acting on the ball during the motion: the force of gravity, which is given by

$F=mg$

where

m is the mass of the ball

g = -9.8 m/s^2 is the acceleration due to gravity

According to Newton's second law, the resultant of the forces acting on the body is equal to the product of mass and acceleration (a), so

$mg = ma$

which means that the acceleration is

$a= g = -9.8 m/s^2$

and the negative sign means it points downward.

7 0

3 years ago

A single-slit diffraction pattern is formed by monochromatic electromagnetic radiation from a distant source passing through a s

tatiyna

Answer:

a. λ = 647.2 nm

b. I₀ 9.36 x 10⁻⁵

Explanation:

Given:

β = 56.0 rad , θ = 3.09 ° , γ = 0.170 mm = 0.170 x 10⁻³ m

a.

The wavelength of the radiation can be find using

β = 2 π / γ * sin θ

λ = [ 2π * γ * sin θ ] / β

λ = [ 2π * 0.107 x 10⁻³m * sin (3.09°) ] / 56.0 rad

λ = 647.14 x 10⁻⁹ m ⇒ λ = 647.2 nm

b.

The intensity of the central maximum I₀

I = I₀ (4 / β² ) * sin ( β / 2)²

I = I₀ (4 / 56.0²) * [ sin (56.0 /2) ]²

I = I₀ 9.36 x 10⁻⁵

8 0

3 years ago
