Calculate the speed of the car at each checkpoint by

1 answer:

3 0

Answer: The speed at the first quarter checkpoint is 0.74 m/s. The speed at the second quarter checkpoint is 1.40 m/s. The speed at the third quarter checkpoint is 1.61 m/s. The speed at the finish line is 1.89 m/s.

Explanation: I did the assignment and got it correct :)

You might be interested in

Several springs are connected as illustrated below in (a). Knowing the individual springs stiffness k1 = 20 N/m, k2 = 30 N/m, k3

Hatshy [7]

Answer:

The equivalent stiffness of the string is 8.93 N/m.

Explanation:

Given that,

Spring stiffness is

$k_{1}=20\ N/m$

$k_{2}=30\ N/m$

$k_{3}=15\ N/m$

$k_{4}=20\ N/m$

$k_{5}=35\ N/m$

According to figure,

$k_{2}$ and $k_{3}$ is in series

We need to calculate the equivalent

Using formula for series

$\dfrac{1}{k}=\dfrac{1}{k_{2}}+\dfrac{1}{k_{3}}$

$k=\dfrac{k_{2}k_{3}}{k_{2}+k_{3}}$

Put the value into the formula

$k=\dfrac{30\times15}{30+15}$

$k=10\ N/m$

k and $k_{4}$ is in parallel

We need to calculate the k'

Using formula for parallel

$k'=k+k_{4}$

Put the value into the formula

$k'=10+20$

$k'=30\ N/m$

$k_{1}$ ,k' and $k_{5}$ is in series

We need to calculate the equivalent stiffness of the spring

Using formula for series

$k_{eq}=\dfrac{1}{k_{1}}+\dfrac{1}{k'}+\dfrac{1}{k_{5}}$

Put the value into the formula

$k_{eq}=\dfrac{1}{20}+\dfrac{1}{30}+\dfrac{1}{35}$

$k_{eq}=8.93\ N/m$

Hence, The equivalent stiffness of the string is 8.93 N/m.

3 0

3 years ago

What would the person’s mass be on the earth? Part B pls

Dafna1 [17]

Answer:

I hopes it helps

thank you

4 0

3 years ago

A rock climber hangs freely from a nylon rope that is 15 m long and has a diameter of 8.3 mm. If the rope stretches 5.1 cm, what

irinina [24]

Answer:

Mass of the climber = 69.38 kg

Explanation:

Change in length

$\Delta L=\frac{PL}{AE}$

Load, P = m x 9.81 = 9.81m

Young's modulus, Y = 0.37 x 10¹⁰ N/m²

Area

$A=\frac{\pi (8.3\times 10^{-3})^2}{4}=5.41\times 10^{-5}m^2$

Length, L = 15 m

ΔL = 5.1 cm = 0.051 m

Substituting

$0.051=\frac{9.81m\times 15}{5.41\times 10^{-5}\times 0.37\times 10^{10}}\\\\m=69.38kg$

Mass of the climber = 69.38 kg

6 0

3 years ago

A 2 kg box of taffy candy has 40j of potential energy relative to the ground. Its height above the ground is

lord [1]

Answer:

2.04m

Explanation:

PE=mgh

h= PE/mg

h= 40/2(9.82)

h=40/19.64

h=2.04

8 0

3 years ago

Read 2 more answers

What is the length of a spring that has 450J of potential energy and a spring constant of 650N/m?

11111nata11111 [884]

Answer:

Δx = 1.2 m

Explanation:

The CHANGE of spring length) (Δx) can be found using PS = ½kΔx²

Δx = √(2PS/k) = √(2(450)/650) = 1.17669... ≈ 1.2 m

The actual length of the spring is unknown as it varies with material type, construction method, extension or compression, and other variables we have no clue about.

4 0
