Alexeev081 [22]
3 years ago
12

Given a program with execution times broken down shown below. Assume that techniques can only be applied to accelerate the integ

er instructions. What is the theoretical upper bound (theoretical maximum) of the speedup that can be achieved? Show your derivation Continued from the previous question, now assume our goal is to redesign the machine to achieve an overall speedup of 2 times. A technique was found to accelerate the floating point instructions by 4x. To achieve our design goal, how much speedup is needed from optimizing the integer instructions?
Engineering
1 answer:
Alex17521 [72]3 years ago
7 0

<u>Solution and Explanation:</u>

Floating point and Integer consumes 1000 seconds of 1600 seconds.

Since we shall be talking of theoretical speed-up, please do not try to relate this with any practical scenario :P

To achieve maximum speed up, we need to reduce the time consumed by FP and Integer as large as possible. So we consider a system that does not at all consume time to perform FP and Integer operations. With such specifications, we can say that our new system will consume 600 seconds.

 speed up = 1600 divide by 600 = 2.66

<u>part b: </u>

We need a System with enhancement that will result in speedup of 2.

So the time required for the new system would be 800 sec

 Required time = 1600 divide by = 800 seconds

It is now given that Floating Point can now be accelerated by 5 times, so our enhanced system will consume 40 seconds to perform Floating point operations

We know that Load/Store and branch operations cannot be enhanced and hence they will consume 600 seconds.

Therefore to attend speedup of 2, Integer operations must be completed in 160 seconds (160 = 800 – (600 + 40))

So speed up required for Integer Operations is 800/160 = 5

So Integer Operation should need 5 times less time to achieve speed up of 2

You might be interested in
Given the inherent costs of regulation it is safe to say that there is always a negative economic impact associated with regulat
Alexus [3.1K]

the answer is true.                                     <u>                    </u>

6 0
2 years ago
Determine the angular acceleration of the uniform disk if (a) the rotational inertia of the disk is ignored and (b) the inertia
lukranit [14]

Answer:

α = 7.848 rad/s^2  ... Without disk inertia

α = 6.278 rad/s^2  .... With disk inertia

Explanation:

Given:-

- The mass of the disk, M = 5 kg

- The right hanging mass, mb = 4 kg

- The left hanging mass, ma = 6 kg

- The radius of the disk, r = 0.25 m

Find:-

Determine the angular acceleration of the uniform disk without and with considering the inertia of disk

Solution:-

- Assuming the inertia of the disk is negligible. The two masses ( A & B )  are hung over the disk in a pulley system. The disk is supported by a fixed support with hinge at the center of the disk.

- We will make a Free body diagram for each end of the rope/string ties to the masses A and B.

- The tension in the left and right string is considered to be ( T ).

- Apply newton's second law of motion for mass A and mass B.

                      ma*g - T = ma*a

                      T - mb*g = mb*a

Where,

* The tangential linear acceleration ( a ) with which the system of two masses assumed to be particles move with combined constant acceleration.

- g: The gravitational acceleration constant = 9.81 m/s^2

- Sum the two equations for both masses A and B:

                      g* ( ma - mb ) = ( ma + mb )*a

                      a =  g* ( ma - mb ) / ( ma + mb )

                      a = 9.81* ( 6 - 4 ) / ( 6 + 4 ) = 9.81 * ( 2 / 10 )

                      a = 1.962 m/s^2

- The rope/string moves with linear acceleration of ( a ) which rotates the disk counter-clockwise in the direction of massive object A.

- The linear acceleration always acts tangent to the disk at a distance radius ( r ).

- For no slip conditions, the linear acceleration can be equated to tangential acceleration ( at ). The correlation between linear-rotational kinematics is given below :

                     a = at = 1.962 m/s^2

                     at = r*α

Where,

           α: The angular acceleration of the object ( disk )

                    α = at / r

                    α = 1.962 / 0.25

                    α = 7.848 rad/s^2

- Take moments about the pivot O of the disk. Apply rotational dynamics conditions:



                Sum of moments ∑M = Iα

                 ( Ta - Tb )*r = Iα

- The moment about the pivots are due to masses A and B.



               Ta: The force in string due to mass A

               Tb: The force in string due to mass B

                I: The moment of inertia of disk = 0.5*M*r^2

                   ( ma*a - mb*a )*r = 0.5*M*r^2*α

                   α = ( ma*a - mb*a ) / ( 0.5*M*r )

                   α = ( 6*1.962 - 4*1.962 ) / ( 0.5*5*0.25 )

                   α = ( 3.924 ) / ( 0.625 )

                   α = 6.278 rad/s^2

6 0
3 years ago
2. The following segment of carotid artery has an inlet velocity of 50 cm/s (diameter of 15 mm). The outlet has a diameter of 11
ahrayia [7]

This question is incomplete, the missing diagram is uploaded along this answer below.

Answer:

the forces required to keep the artery in place is 1.65 N

Explanation:

Given the data in the question;

Inlet velocity V₁ = 50 cm/s = 0.5 m/s

diameter d₁ = 15 mm = 0.015 m

radius r₁ = 0.0075 m

diameter d₂ = 11 mm = 0.011 m

radius r₂ = 0.0055 m

A₁ = πr² = 3.14( 0.0075 )² =  1.76625 × 10⁻⁴ m²

A₂ = πr² = 3.14( 0.0055 )² =  9.4985 × 10⁻⁵ m²

pressure at inlet P₁ = 110 mm of Hg = 14665.5 pascal

pressure at outlet P₂ = 95 mm of Hg = 12665.6 pascal

Inlet volumetric flowrate = A₁V₁ = 1.76625 × 10⁻⁴ × 0.5 = 8.83125 × 10⁻⁵ m³/s

given that; blood density is 1050 kg/m³

mass going in m' = 8.83125 × 10⁻⁵ m³/s × 1050 kg/m³ = 0.092728 kg/s

Now, using continuity equation

A₁V₁ = A₂V₂

V₂ = A₁V₁ / A₂ = (d₁/d₂)² × V₁

we substitute

V₂ =  (0.015 / 0.011 )² × 0.5

V₂ = 0.92975 m/s

from the diagram, force balance in x-direction;

0 - P₂A₂ × cos(60°) + Rₓ = m'( V₂cos(60°) - 0 )

so we substitute in our values

0 - (12665.6 × 9.4985 × 10⁻⁵)  × cos(60°) + Rₓ = 0.092728( 0.92975 cos(60°) - 0 )

0 - 0.6014925 + Rₓ =  0.043106929 - 0

Rₓ = 0.043106929 + 0.6014925

Rₓ = 0.6446 N

Also, we do the same force balance in y-direction;

P₁A₁ - P₂A₂ × sin(60°) + R_y = m'( V₂sin(60°) - 0.5 )

we substitute

⇒ (14665.5 × 1.76625 × 10⁻⁴) - (12665.6 × 9.4985 × 10⁻⁵) × sin(60°) + R_y = 0.092728( 0.92975sin(60°) - 0.5 )

⇒ 1.5484 + R_y = 0.092728( 0.305187 )

⇒ 1.5484 + R_y = 0.028299

R_y = 0.028299 - 1.5484

R_y = -1.52 N

Hence reaction force required will be;

R = √( Rₓ² + R_y² )

we substitute

R = √( (0.6446)² + (-1.52)² )

R = √( 0.41550916 + 2.3104 )

R = √( 2.72590916 )

R = 1.65 N

Therefore, the forces required to keep the artery in place is 1.65 N



7 0
2 years ago
A 3.5-m3 rigid tank initially contains air whose density is 2 kg/m3 . The tank is connected to a high-pressure supply line throu
Mumz [18]

Answer:

Explanation:

First, we find the mass of the air originally in the tank.

Density is given as mass divided by volume. It is given as:

Density = \frac{mass}{volume}

Therefore, mass is:

mass = denisty *volume

Density of air = 2 kg/m^3; Volume of the tank =  3.5 m^3

=> Mass = 3.5 * 2 = 7 kg

The mass of the air initially in the tank is 7 kg.

After air is allowed to enter, the mass changes.

New density = 6.5 kg/m^3

The new mass will be:

Mass = 6.5 * 3.5 = 22.75 kg

We can now find the mass of air that has entered the tank:

Mass of air that entered tank = New mass of air - Original mass of air

M = 22.75 - 7.0 = 15.75 kg

The mass of air that entered the tank is 15.75 kg.

6 0
3 years ago
EggzOG43199 <br><br><br><br> :) it has to be more than 20 characters so I'm just saying this
lawyer [7]

Answer:

giberishgiberishgiberishgiberishgiberishgiberishgiberishgiberishgiberish

Explanation:

i have no idea what the question is but do u 4 real need help?

8 0
2 years ago
