kati45 [8]
4 years ago
8

Air is used as the working fluid in a simple ideal Brayton cycle that has a pressure ratio of 12, a compressor inlet temperature

of 300 K, and a turbine inlet temperature of 1000 K. Determine the required mass flow rate of air for a net power output of 70 MW, assuming both the compressor and the turbine have an isentropic efficiency of (a) 100 percent and (b) 85 percent. Assume constant specific heats at room temperature

Engineering
1 answer:
MissTica4 years ago
6 0

Answer:

Draw the ideal Brayton cycle on the diagram.

Explanation:

Draw the ideal Brayton cycle on the diagram.

See attachment
