Answer:
Check attachment for solution
Explanation:
Given that 12V battery
Answer:
Explanation:
1. Impulse, I = F.t
The statement impulse is the product of Force and distance is false.
2. F = m g
Force necessary to lift the object depends on the mass of the object.
statement 2 is false.
3. Joule is equal to Newton times meter.
Statement 3 is false.
4. Work done to lift an object is correct statement.
Statement 4 is true.
5. Kinetic energy of an object is due to motion.
Statement 5 is false.
6. Stopping distance is directly proportional to the square of velocity.
If velocity is doubled, stopping distance is quadrupled.
Statement 6 is false.
Answer:
Normal stress = 66/62.84 = 1.05kips/in²
shearing stress = T/2 = 0.952/2 = 0.476 kips/in²
Explanation:
A steel pipe of 12-in. outer diameter d₂ =12in d₁= 12 -4in = 8in
4 -in.-thick
angle of 25°
Axial force P = 66 kip axial force
determine the normal and shearing stresses
Normal stress б = force/area = P/A
= 66/ (П* (d₂²-d₁²)/4
=66/ (3.142* (12²-8²)/4
= 66/62.84 = 1.05kips/in²
Tangential stress T = force* cos ∅/area = P/A
= 66* cos 25/ (П* (d₂²-d₁²)/4
=59.82/ (3.142* (12²-8²)/4
= 59.82/62.84 = 0.952kips/in²
shearing stress = tangential stress /2
= T/2 = 0.952/2 = 0.476 kips/in²
Answer:
Energy required = 3169.34 Joules.
Explanation:
The quantity of energy (Q) required can be determined by;
Q = mcΔθ
Where: m is the mass, c is the specific heat and Δθ is the change in temperature.
But, m = 96.7 kg, c = 0.874 J/(kg
),
=
and
=
.
So that,
Q = mc( - )
= 96.7 x 0.874 x ( - )
= 96.7 x 0.874 x 37.5
= 3169.3425
Q = 3169.34
= 3.2 KJ
The amount of energy required is 3169.34 Joules.
Answer:
34.51
Explanation:
k=1/2mv² is the kenetic energy equation to fill is in
k=[1/2(0.235)×50]²
