A block lies on a plane raised an angle θ from the horizontal. Three forces act upon the block: F⃗ w, the force of gravity; F⃗ n

Verdich [7]

Answer:

YFy = 0 = Ffsinθ + Fncosθ - Fw

Explanation:

From the base of the vector Fn, draw a vertical line. the small angle between this line and Fn is also theta. The component of Fn in the vertical direction is Fncos(theta).

Take a moment to picture extreme cases. Sine is 0 at 0 and 1 at 90. Cosine is 1 at 0 and 0 at 90.

Tilt the incline so that the box is on a flat surface. How much of the gravitational force is along the x direction of the floor.

5 0

3 years ago

A mass weighing 24 pounds, attached to the end of a spring, stretches it 4 inches. Initially, the mass is released from rest fro

svetoff [14.1K]

Answer:

The equation of motion is $x(t)=-$ $\frac{1}{3} cos4\sqrt{6t}$

Explanation:

Lets calculate

The weight attached to the spring is 24 pounds

Acceleration due to gravity is $32ft/s^2$

Assume x , is spring stretched length is ,4 inches

Converting the length inches into feet $x=\frac{4}{12} =\frac{1}{3}feet$

The weight (W=mg) is balanced by restoring force ks at equilibrium position

mg=kx

$W=kx$ ⇒ $k=\frac{W}{x}$

The spring constant , $k=\frac{24}{1/3}$

= 72

If the mass is displaced from its equilibrium position by an amount x, then the differential equation is

$m\frac{d^2x}{dt} +kx=0$

$\frac{3}{4} \frac{d^2x}{dt} +72x=0$

$\frac{d^2x}{dt} +96x=0$

Auxiliary equation is, $m^2+96=0$

$m=\sqrt{-96}$

= $\frac{+}{} i4\sqrt{6}$

Thus , the solution is $x(t)=c_1cos4\sqrt{6t}+c_2sin4\sqrt{6t}$

$x'(t)=-4\sqrt{6c_1} sin4\sqrt{6t}+c_2$ $4\sqrt{6}$ $cos4\sqrt{6t}$

The mass is released from the rest x'(0) = 0

$=-4\sqrt{6c_1} sin4\sqrt{6(0)}+c_2$ $4\sqrt{6}$ $cos4\sqrt{6(0)}$ =0

$c_2$ $4\sqrt{6} =0$

$c_2=0$

Therefore , $x(t)=c_1$ $cos 4\sqrt{6t}$

Since , the mass is released from the rest from 4 inches

$x(0)= -4$ inches

$c_1 cos 4\sqrt{6(0)} =-\frac{4}{12}$ feet

$c_1=-\frac{1}{3}$ feet

Therefore , the equation of motion is $-\frac{1}{3} cos4\sqrt{6t}$

7 0

2 years ago

Twins Jody and Taylor are rearranging the furniture in their bedroom and want to move a dresser across the room. The dresser has

xeze [42]

Answer:

yes, They will be able to move the dresser.

Explanation:

sliding force 90N

55N + 38N = 93N

therefore, yes the twins can move the dresser

7 0

3 years ago

Hi im a little stuck on this question that came from my textbook in class it got a little confusing for me because i really dont

koban [17]

Consult the attached free body diagram.

By Newton's second law, the net force on the crate acting parallel to the surface is

∑ F[para] = (370 N) cos(-20°) - f = 0

(this is the x-component of the resultant force)

where

• (370 N) cos(-20°) = magnitude of the horizontal component of the pushing force

• f = magnitude of kinetic friction

The crate is moving at a constant speed and thus not accelerating, so the crate is in equilibrium.

Solve for f :

f = (370 N) cos(-20°) ≈ 347.686 N

The net force acting perpendicular to the surface is

∑ F[perp] = n - 1480 N - (370 N) sin(-20°) = 0

(this is the y-component of the resultant force)

where

• n = magnitude of normal force

• 1480 N = weight of the crate

• (370 N) sin(-20°) = magnitude of the vertical component of push

The crate doesn't move up or down, so it's also in equilibrium in this direction.

Solve for n :

n = 1480 N + (370 N) sin(-20°) ≈ 1606.55 N ≈ 1610 N

Then the coefficient of kinetic friction is µ such that

f = µn ⇒ µ = f/n ≈ 0.216

7 0

2 years ago

Two students measure the time constant of an RC circuit. The first student charges the capacitor using a 12 V battery, then lets

luda_lava [24]

Answer:

The answer is: c.) Both students get the same time constant, since the time constant does not depend on the charge on the capacitor

Explanation:

Both students, because the time constant is not dependent on the capacitor charge. We can express the equation of the time constant as follows:

Time constant = RC

In this equation it is observed that the time constant is equal to the multiplication of the resistance (R) multiplied by the capacitance (C)

8 0

3 years ago
