A cylindrical capacitor has an inner conductor of radius 2.7 mmmm and an outer conductor of radius 3.1 mmmm. The two conductors

Mars2501 [29]

Answer:

(A) Capacitance per unit length = $4.02 \times 10^{-10}$

(B) The magnitude of charge on both conductor is $Q = 4.22 \times 10^{-19}$ C and the sign of charge on inner conductor is $+Q$ and the sign on outer conductor is $-Q$

Explanation:

Given :

Radius of inner part of conductor $(R_{1})$ = $2.7 \times 10^{-3}$ m

Radius of outer part of conductor $(R_{2})$ = $3.1 \times 10^{-3}$ m

The length of the capacitor $(l)$ = $3 \times 10^{-3}$ m

(A)

Capacitance is purely geometrical property. It depends only on length, radius of conductor.

From the formula of cylindrical capacitor,

$C = \frac{2\pi\epsilon_{o} l }{ln\frac{R_{2} }{R_{1} } }$

Where, $\epsilon_{o} = 8.85 \times 10^{-12}$

But we need capacitance per unit length so,

$\frac{C}{l} = \frac{2\pi\epsilon_{o} }{ln\frac{R_{2} }{R_{1} } }$

capacitance per unit length = $\frac{6.28 \times 8.85 \times 10^{-12} }{ln(1.148)} = 4.02 \times 10^{-10}$

(B)

The charge on both conductors is given by,

$Q = C \Delta V$

Where, C = capacitance of cylindrical capacitor and value of $C = 12.06 \times 10^{-13}$ F, $\Delta V = 350 \times 10^{-3}$ V

∴ $Q = 4.22 \times 10^{-19}$ C

The magnitude of charge on both conductor is same as above but the sign of charge is different.

Charge on inner conductor is $+Q$ and Charge on outer conductor is $-Q$ .

8 0

4 years ago

The equation shows neutralization of an acid and a base to produce a salt and water.

Lyrx [107]

This equation will be balanced if the x is a 2 because there are two sodiums on the reactants sides so there must be two sodiums on the products side

Hope this helps

7 0

3 years ago

Read 2 more answers

Janessa got through high school easily because she could remember what her teachers said in class and their tests never covered

VMariaS [17]

CorrectThe direction of the electric field stays the same regardless of the sign of the charges that are free to move in theconductor.Mathematically, you can see that this must be true since the expression you derived for the electric field isindependent of .Physically, this is because the force due to the magnetic field changes sign as well and causes positive charges tomove in the direction (as opposed to pushing negative charges in the direction). Therefore the result isalways the same: positive charges on the side and negative charges on the side. Because the electric fieldgoes from positive to negative charges will always point in the direction (given the original directions of

8 0

3 years ago

Friction provides the force needed for a car to travel around a flat, circular race track. What is the maximum speed at which a

blagie [28]

Answer:

The maximum speed at which the car can safety travel around the track is 18.6m/s.

Explanation:

Since the car is in circular motion, there has to be a centripetal force $F_c$ . In this case, the only force that applies for that is the static frictional force $f_s$ between the tires and the track. Then, we can write that:

$f_s=F_c$

And since $f_s\leq \mu N$ and $F_c=\frac{mv^{2}}{r}$ , we have:

$\mu N\geq \frac{mv^{2}}{r}$

Now, if we write the vertical equation of motion of the car (in which there are only the weight and the normal force), we obtain:

$N-mg=0\\\\\\implies N=mg$

Substituting this expression for $N$ and solving for $v$ , we get:

$\mu mg\geq \frac{mv^{2}}{r}\\\\v\leq \sqrt{\mu gr}$

Finally, plugging in the given values for the coefficient of friction and the radius of the track, we have:

$v\leq \sqrt{(0.42)(9.81m/s^{2})(84.0m)}\\\\v\leq 18.6m/s$

It means that in its maximum value, the speed of the car is equal to 18.6m/s.

7 0

3 years ago

Read 2 more answers

a hot pot of water is set on the counter to cool. after a few minutes it has lost 755 j of heat energy. how much heat energy has

velikii [3]

The heat energy the surrounding air gained is 755 j.

Energy is a quantitative property given to a body or physical system and can be identified as work being done in the form of heat and light. Energy is Conserved - The law of conservation of energy states that energy can be transformed into form, but cannot be created or destroyed. Energy is the ability to do work. It can exist in electrical, kinetic, thermal, electrical, chemical, nuclear, or other forms.

Concept:-

Since the energy is always conserved, the energy lost by the hot water is gained bt the surrounding

- energy lost = + energy gained by the surrounding

- 755 j = + 755 j

Energy exists in many forms. Examples include light energy, thermal energy, mechanical energy, gravitational energy, electrical energy, acoustic energy, chemical energy, and nuclear or atomic energy. Each form can be transformed or changed into other forms.

Learn more about energy here:-brainly.com/question/13881533

#SPJ1

5 0

1 year ago
