Nitrogen gas is compressed at steady state from a pressure of 14.2 psi and a temperature 60o F to a pressure of 120 psi and a te

mperature of 500o F. The gas enters a compressor with a volumetric flow rate of 1200 ft3 /min. The magnitude of the heat transfer rate from the compressor to its surroundings is 5% of the compressor power input. Using the ideal gas model (with variable specific heats) and neglecting kinetic and potential energy effects, determine (a) The compressor power input (in horsepower). (b) The volumetric flow rate at the exit (in ft3 /min).
Engineering
1 answer:
brilliants [131]3 years ago
5 0

Answer:

a) 229.4281 hp.

b) 262.15 ft3/min.

Explanation:

Given data:

P1 = 14.2 psi

T1 = 60°F = 520° R

P2 = 120 psi

T2 = 500°F = 960° R

volumetric flow rate ( Av1 ) = 1200 ft^3 /min = 20 ft^3 / sec

attached below is the detailed solution

You might be interested in
A rigid insulated tank is divided into 2 equal compartments by a thin rigid partition. One of the compartments contains air, ass
Illusion [34]
Https://www.slader.com/discussion/question/an-insulated-rigid-tank-is-divided-into-two-equal-parts-by-a-partition-initially-one-part-contains-4/



there will be the answer

6 0
2 years ago
Air at 26 kPa, 230 K, and 220 rn/s enters a turbojet engine in flight. The air mass flow rate is 25 kg/s. The compressor pressur
Paha777 [63]

Answer:

Explanation:

Answer:

Explanation:

Answer:

Explanation:

This is a little lengthy and tricky, but nevertheless i would give a step by step analysis to make this as simple as possible.

(a). here we are asked to determine the Temperature and Pressure.

Given that the properties of Air;

ha = 230.02 KJ/Kg

Ta = 230 K

Pra = 0.5477

From the energy balance equation for a diffuser;

ha + Va²/2 = h₁ + V₁²/2

h₁ = ha + Va²/2 (where V₁²/2 = 0)

h₁ = 230.02 + 220²/2 ˣ 1/10³

h₁ = 254.22 KJ/Kg

⇒ now we obtain the properties of air at h₁ = 254.22 KJ/Kg

from this we have;

Pr₁ = 0.7329 + (0.8405 - 0.7329)[(254.22 - 250.05) / (260.09 - 250.05)]

Pr₁ = 0.77759

therefore T₁ = 254.15K

P₁ = (Pr₁/Pra)Pa

= 0.77759/0.5477 ˣ 26

P₁ = 36.91 kPa

now we calculate Pr₂

Pr₂ = Pr₁ (P₂/P₁) = 0.77759 ˣ 11 = 8.55349

⇒ now we obtain properties of air at

Pr₂ = 8.55349 and h₂ = 505.387 KJ/Kg

calculating the enthalpy of air at state 2

ηc = h₁ - h₂ / h₁ - h₂

0.85 = 254.22 - 505.387 / 254.22 - h₂

h₂ = 549.71 KJ/Kg

to obtain the properties of air at h₂ = 549.71 KJ/Kg

T₂ = 545.15 K

⇒ to calculate the pressure of air at state 2

P₂/P₁ = 11

P₂ = 11 ˣ 36.913

p₂ = 406.043 kPa

but pressure of air at state 3 is the same,

i.e. P₂ = P₃ = 406.043 kPa

P₃ = 406.043 kPa

To obtain the properties of air at

T₃ = 1400 K, h₃ = 1515.42 kJ/Kg and Pr = 450.5

for cases of turbojet engine,

we have that work output from turbine = work input to the compressor

Wt = Wr

(h₃ - h₄) = (h₂ - h₁)

h₄ = h₃ - h₂ + h₁

= 1515.42 - 549.71 + 254.22

h₄ = 1219.93 kJ/Kg

properties of air at h₄ = 1219.93 kJ/Kg

T₄ = 1140 + (1160 - 1140) [(1219.93 - 1207.57) / (1230.92 - 1207.57)]

T₄ = 1150.58 K

Pr₄ = 193.1 + (207.2 - 193.1) [(1219.93 - 1207.57) / (1230.92 - 1207.57)]

Pr₄ = 200.5636

Calculating the ideal enthalpy of the air at state 4;

Лr = h₃ - h₄ / h₃ - h₄*

0.9 = 1515.42 - 1219.93 / 1515.42 - h₄

h₄* = 1187.09 kJ/Kg

now to obtain the properties of air at h₄⁻ = 1187.09 kJ/Kg

P₄* = 179.7 + (193.1 - 179.7) [(1187.09 -1184.28) / (1207.57 - 1184.28)]

P₄* = 181.316

P₄ = (Pr₄/Pr₃)P₃       i.e. 3-4 isentropic process

P₄ = 181.316/450.5 * 406.043

P₄ = 163.42 kPa

For the 4-5 process;

Pr₅ = (P₅/P₄)Pr₄

Pr₅ = 26/163.42 * 200.56 = 31.9095

to obtain the properties of air at Pr₅ = 31.9095

h₅= 724.04 + (734.82 - 724.04) [(31.9095 - 3038) / (32.02 - 30.38)]

h₅ = 734.09 KJ/Kg

T₅ = 710 + (720 - 710) [(31.9095 - 3038) / (32.02 - 30.38)]

T₅ = 719.32 K

(b) Now we are asked to calculate the rate of heat addition to the air passing through the combustor;

QH = m(h₃-h₂)

QH = 25(1515.42 - 549.71)

QH = 24142.75 kW

(c). To calculate the velocity at the nozzle exit;

we apply steady energy equation of a flow to nozzle

h₄ + V₄²/2 = h₅ + V₅²/2

h₄  + 0  = h₅₅ + V₅²/2

1219.9 ˣ 10³ = 734.09 ˣ 10³ + V₅²/2

therefore, V₅ = 985.74 m/s

cheers i hope this helps

6 0
3 years ago
Sketches are a very efficient way to share ideas.<br> True<br> False
timurjin [86]

Answer:

yes

Explanation:

4 0
3 years ago
Read 2 more answers
You want to plate a steel part having a surface area of 160 with a 0.002--thick layer of lead. The atomic mass of lead is 207.19
Pepsi [2]

Answer:

<u><em>To answer this question we assumed that the area units and the thickness units are given in inches.</em></u>

The number of atoms of lead required is 1.73x10²³.

Explanation:

To find the number of atoms of lead we need to find first the volume of the plate:

V = A*t

<u>Where</u>:

A: is the surface area = 160

t: is the thickness = 0.002

<u><em>Assuming that the units given above are in inches we proceed to calculate the volume: </em></u>

V = A*t = 160 in^{2}*0.002 in = 0.32 in^{3}*(\frac{2.54 cm}{1 in})^{3} = 5.24 cm^{3}

Now, using the density we can find the mass:

m = d*V = 11.36 g/cm^{3}*5.24 cm^{3} = 59.5 g

Finally, with the Avogadros number (N_{A}) and with the atomic mass (A) we can find the number of atoms (N):

N = \frac{m*N_{A}}{A} = \frac{59.5 g*6.022 \cdot 10^{23} atoms/mol}{207.19 g/mol} = 1.73 \cdot 10^{23} atoms

Hence, the number of atoms of lead required is 1.73x10²³.

I hope it helps you!

3 0
3 years ago
. Using the Newton Raphson method, determine the uniform flow depth in a trapezoidal channel with a bottom width of 3.0 m and si
Over [174]

Answer:

y  ≈ 2.5

Explanation:

Given data:

bottom width is 3 m

side slope is 1:2

discharge is 10 m^3/s

slope is 0.004

manning roughness coefficient is 0.015

manning equation is written as

v =1/n R^{2/3} s^{1/2}

where R is hydraulic radius

S = bed slope

Q = Av =A 1/n R^{2/3} s^{1/2}

A = 1/2 \times (B+B+4y) \times y =(B+2y) y

R =\frac{A}{P}

P is perimeter =  (B+2\sqrt{5} y)

R =\frac{(3+2y) y}{(3+2\sqrt{5} y)}

Q = (2+2y) y) \times 1/0.015 [\frac{(3+2y) y}{(3+2\sqrt{5} y)}]^{2/3} 0.004^{1/2}

solving for y100 =(2+2y) y) \times (1/0.015) [\frac{(3+2y) y}{(3+2\sqrt{5} y)}]^{2/3} \times 0.004^{1/2}

solving for y value by using iteration method ,we get

y  ≈ 2.5

5 0
3 years ago
