View the photo below, read the passage, and answer the question.

In an experiment, a variable, position-dependent force F(x)F(x) is exerted on a block of mass 1.0kg1.0kg that is moving on a hor

leonid [27]

Answer:

The function F(x) for 0 < x < 5, the block's initial velocity, and the value of F(f).

(C) is correct option.

Explanation:

Given that,

Mass of block = 1.0 kg

Dependent force = F(x)

Frictional force = F(f)

Suppose, the following information would students need to test the hypothesis,

(A) The function F(x) for 0 < x < 5 and the value of F(f).

(B) The function a(t) for the time interval of travel and the value of F(f).

(C) The function F(x) for 0 < x < 5, the block's initial velocity, and the value of F(f).

(D) The function a(t) for the time interval of travel, the time it takes the block to move 5 m, and the value of F(f).

(E) The block's initial velocity, the time it takes the block to move 5 m, and the value of F(f).

We know that,

The work done by a force is given by,

$W=\int_{x_{0}}^{x_{f}}{F(x)\ dx}$ .....(I)

Where, $F(x)$ = net force

We know, the net force is the sum of forces.

So, $\sum{F}=ma$

According to question,

We have two forces F(x) and F(f)

So, the sum of these forces are

$F(x)+(-F(f))=ma$

Here, frictional force is negative because F(f) acts against the F(x)

Now put the value in equation (I)

$W=\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}$

We need to find the value of $\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}$

Using newton's second law

$\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}=\int_{x_{0}}^{x_{f}}{ma\ dx}$ ...(II)

We know that,

Acceleration is rate of change of velocity.

$a=\dfrac{dv}{dt}$

Put the value of a in equation (II)

$\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}=\int_{x_{0}}^{x_{f}}{m\dfrac{dv}{dt}dx}$

$\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}=\int_{v_{0}}^{v_{f}}{mv\ dv}$

$\int_{x_{0}}^{x_{f}}{(F(x)-F(f))dx}=\dfrac{mv_{f}^2}{2}+\dfrac{mv_{0}^2}{2}$

Now, the work done by the net force on the block is,

$W=\dfrac{mv_{f}^2}{2}+\dfrac{mv_{0}^2}{2}$

The work done by the net force on the block is equal to the change in kinetic energy of the block.

Hence, The function F(x) for 0 < x < 5, the block's initial velocity, and the value of F(f).

(C) is correct option.

7 0

3 years ago

A singly charged positive ion has a mass of 3.46 × 10−26 kg. After being accelerated through a potential difference of 215 V the

jasenka [17]

Answer:

1.8 cm

Explanation:

$m$ = mass of the singly charged positive ion = 3.46 x 10⁻²⁶ kg

$q$ = charge on the singly charged positive ion = 1.6 x 10⁻¹⁹ C

$\Delta V$ =Potential difference through which the ion is accelerated = 215 V

$v$ = Speed of the ion

Using conservation of energy

Kinetic energy gained by ion = Electric potential energy lost

$(0.5) m v^{2} = q \Delta V\\(0.5) (3.46\times10^{-26}) v^{2} = (1.6\times10^{-19}) (215)\\(1.73\times10^{-26}) v^{2} = 344\times10^{-19}\\v = 4.5\times10^{4} ms^{-1}$

$r$ = Radius of the path followed by ion

$B$ = Magnitude of magnetic field = 0.522 T

the magnetic force on the ion provides the necessary centripetal force, hence

$qvB = \frac{mv^{2} }{r} \\qB = \frac{mv}{r}\\r =\frac{mv}{qB}\\r =\frac{(3.46\times10^{-26})(4.5\times10^{4})}{(1.6\times10^{-19})(0.522)}\\r = 0.018 m \\r = 1.8 cm$

5 0

3 years ago

A projectile is launched from the ground with an initial velocity of 12ms at an angle of 30° above the horizontal. The projectil

netineya [11]

$vi^{2}sin2thita/g =12^{2}sin2[30]/9.8=12.7$ Answer:

Explanation:

range is given as

6 0

3 years ago

Read 2 more answers

Since many wavelengths of light are measured in nanometers, it's useful to know that planck's constant (h) multiplied with the s

MrRa [10]

Answer:

E = h f and since f = c / λ we have E = h c / λ

Thus λ = h c / E

Also, 1 ev = 1.6E-19 C

λ = 6.63E-34 * 3.0E8 / (1.6 * 1.6E-19)

λ = 6.63 * 3.0 / (1.6 * 1.6) * E-7

λ = 7.77E-7 = 777 nanometers

(B) is correct

4 0

2 years ago

during a magic show, a magician quickly pulls a tablecloth off of a table set with dishes without disturbing the dishes. what la

Alina [70]

Answer:

Newton's first law of Inertia.

Explanation:

This explains how a magician is able to remove a tablecloth from under dishes and glasses on the table without disturbing them. Because of the mass of the object, it remains in inertia. The Tablecloth, in this trick, is slippery so that it does not have any real friction with glasses and dishes.

4 0

3 years ago
