What is a cyclotron?? What is cyclotron frequency?

1 answer:

timurjin [86]3 years ago

5 0

Answer:

A cyclotron is a type of particle accelerator.

Explanation:

Cyclotron frequency is the frequency of a charged particle moving perpendicular to the direction of a uniform magnetic field B, since that motion is always circular, the cyclotron frequency is given by equality of centripetal force and magnetic Lorentz force.

You might be interested in

a lorry travels 3600m on a test track accelerating constantly at 3m/s squared from standstill. what is the final velocity (3 sig

suter [353]

The final velocity of the truck is found as 146.969 m/s.

Explanation:

As it is stated that the lorry was in standstill position before travelling a distance or covering a distance of 3600 m, the initial velocity is considered as zero. Then, it is stated that the lorry travels with constant acceleration. So we can use the equations of motion to determine the final velocity of the lorry when it reaches 3600 m distance.

Thus, a initial velocity (u) = 0, acceleration a = 3 m/s² and the displacement s is 3600 m. The third equation of motion should be used to determine the final velocity as below.

$2as =v^{2} - u^{2} \\\\v^{2} = 2as + u^{2}$

Then, the final velocity will be

$v^{2} = 2 * 3 * 3600 + 0 = 21600\\ \\v=\sqrt{21600}=146.969 m/s$

Thus, the final velocity of the truck is found as 146.969 m/s.

8 0

3 years ago

The force exerted by electrically changed objects

MAVERICK [17]

Answer:

Electrostatic Force...or a non-contact force

Explanation:

8 0

3 years ago

A load of 54 N attached to a spring that ishanging vertically stretches the spring 0.15 m.What is the spring constant?Answer in

beks73 [17]

Answer:

300 N/m

Explanation:

given,

Load attached to the spring, W = 54 N

length of stretch of the spring, x = 0.15 m

spring constant= ?

Force applied on the spring is calculated by the equation

F = k x

where k is the spring constant

x is the displacement of the spring due to applied load

now,

54 = k × 0.15

$k = \dfrac{54}{0.15}$

$k =300\ N/m$

hence, the spring constant is equal to 300 N/m

8 0

3 years ago

Read 2 more answers

Two resistors R1 = 3 Ω and R2 = 6 Ω are connected in parallel. What is the net resistance in the circuit?

gtnhenbr [62]

Answer:

"2Ω" is the net resistance in the circuit.

Explanation:

The given resistors are:

R1 = 3Ω

R2 = 6Ω

The net resistance will be:

⇒ $\frac{1}{R_{net}} =\frac{1}{R_1} +\frac{1}{R_2}$

On substituting the values, we get

⇒ $\frac{1}{R_{net}} =\frac{1}{3} +\frac{1}{6}$

On taking L.C.M, we get

⇒ $\frac{1}{R_{net}} =\frac{2+1}{6}$

⇒ $\frac{1}{R_{net}} =\frac{3}{6}$

⇒ $\frac{1}{R_{net}} =\frac{1}{2}$

On applying cross-multiplication, we get

⇒ $R_{net}=2 \Omega$

3 0

2 years ago

The ballistic pendulum is a device used to measure the speed of a projectile such as a bullet. The projectile of mass m is fired

My name is Ann [436]

Answer:

Relation between initial speed of bullet and height h is given as

$v = \frac{m + M}{m}\sqrt{2gh}$

Explanation:

As we know that system of block and bullet swings up to height h after collision

So we have

$(m + M)gh = \frac{1}{2}(m + M)v_1^2$

so we have

$v_1 = \sqrt{2gh}$

so speed of the block + bullet just after the impact is given by above equation

Now we also know that there is no force on the system of bullet + block in the direction of motion

So we can use momentum conservation

$mv = (m + M)v_1$

now we have

$v = \frac{m + M}{m}\sqrt{2gh}$

5 0

3 years ago
