What type of engineering do you think would help solve this SDG???

A student takes 60 voltages readings across a resistor and finds a mean voltage of 2.501V with a sample standard deviation of 0.

Lena [83]

Answer:

There are 2 expected readings greater than 2.70 V

Solution:

As per the question:

Total no. of readings, n = 60 V

Mean of the voltage, $\mu = 2.501 V$

standard deviation, $\sigma = 0.113 V$

Now, to find the no. of readings greater than 2.70 V, we find:

The probability of the readings less than 2.70 V, $P(X\leq 2.70)$ :

$z = \frac{x - \mu}{\sigma} = \frac{2.70 - 2.501}{0.113} = 1.761$

Now, from the Probability table of standard normal distribution:

$P(z\leq 1.761) = 0.9608$

Now,

$P(X\geq 2.70) = 1 - P(X\leq 2.70) = 1 - 0.9608 = 0.0392 = 3.92%$

Now, for the expected no. of readings greater than 2.70 V:

$P(X\geq 2.70) = \frac{No.\ of\ readings\ expected\ to\ be\ greater\ than\ 2.70\ V}{Total\ no.\ of\ readings}$

No. of readings expected to be greater than 2.70 V = $P(X\geq 2.70)\times Total\ no.\ of\ readings$

No. of readings expected to be greater than 2.70 V = $0.0392\times 60 = 2.352$ ≈ 2

7 0

3 years ago

Consider a refrigerator that consumes 320 W of electric power when it is running. If the refrigerator runs only one quarter of t

Semenov [28]

Answer:

B. $5.18

Explanation:

Cost of electricity per kWh = $0.09

Power consumption of refrigerator = 320W = 320/1000 = 0.32kW

In a month (30 days) the refrigerator works 1/4 × 30 days = 7.5 days = 7.5 × 24 hours = 180 hours

Energy consumed in 180 hours = 0.32kW × 180h = 57.6kWh

Cost of electricity of 57.6kWh energy consumed by the refrigerator = 57.6 × $0.09 = $5.18

3 0

3 years ago

Read 2 more answers

I’m building a pc, but I only have 2 sata cables. What are the other required cables to connect to or parts, such as the gpu?

Usimov [2.4K]

Answer:

You would also need power cables.

3 0

3 years ago

Read 2 more answers

A counter-flow double-piped heat exchange is to heat water from 20oC to 80oC at a rate of 1.2 kg/s. The heating is to be accompl

lawyer [7]

Answer:

110 m or 11,000 cm

Explanation:

let mass flow rate for cold and hot fluid = Mc and Mh respectively
let specific heat for cold and hot fluid = Cpc and Cph respectively
let heat capacity rate for cold and hot fluid = Cc and Ch respectively

Mc = 1.2 kg/s and Mh = 2 kg/s

Cpc = 4.18 kj/kg °c and Cph = 4.31 kj/kg °c

Using effectiveness-NUT method

First, we need to determine heat capacity rate for cold and hot fluid, and determine the dimensionless heat capacity rate

Cc = Mc × Cpc = 1.2 kg/s × 4.18 kj/kg °c = 5.016 kW/°c

Ch = Mh × Cph = 2 kg/s × 4.31 kj/kg °c = 8.62 kW/°c

From the result above cold fluid heat capacity rate is smaller

Dimensionless heat capacity rate, C = minimum capacity/maximum capacity

C= Cmin/Cmax

C = 5.016/8.62 = 0.582

.2 Second, we determine the maximum heat transfer rate, Qmax

Qmax = Cmin (Inlet Temp. of hot fluid - Inlet Temp. of cold fluid)

Qmax = (5.016 kW/°c)(160 - 20) °c

Qmax = (5.016 kW/°c)(140) °c = 702.24 kW

.3 Third, we determine the actual heat transfer rate, Q

Q = Cmin (outlet Temp. of cold fluid - inlet Temp. of cold fluid)

Q = (5.016 kW/°c)(80 - 20) °c

Qmax = (5.016 kW/°c)(60) °c = 303.66 kW

.4 Fourth, we determine Effectiveness of the heat exchanger, ε

ε = Q/Qmax

ε = 303.66 kW/702.24 kW

ε = 0.432

.5 Fifth, using appropriate effective relation for double pipe counter flow to determine NTU for the heat exchanger

NTU = $\\ \frac{1}{C-1} ln(\frac{ε-1}{εc -1} )$

NTU = $\frac{1}{0.582-1} ln(\frac{0.432 -1}{0.432 X 0.582 -1} )$

NTU = 0.661

.6 sixth, we determine Heat Exchanger surface area, As

From the question, the overall heat transfer coefficient U = 640 W/m²

As = $\frac{NTU C{min} }{U}$

As = $\frac{0.661 x 5016 W. °c }{640 W/m²}$

As = 5.18 m²

.7 Finally, we determine the length of the heat exchanger, L

L = $\frac{As}{\pi D}$

L = $\frac{5.18 m² }{\pi (0.015 m)}$

L= 109.91 m

L ≅ 110 m = 11,000 cm

3 0

3 years ago

The hot combustion gases of a furnace are separated from the ambient air and its surroundings, which are at 25 oC, by a brick wa

yanalaym [24]

Answer:

T1 = 625.54 K

Explanation:

We are given;

T_α = Tsur = 25°C = 298K

h = 20 W/m².K,

L = 0.15 m

K = 1.2 W/m.K

ε = 0.8

Ts = T2 = 100°C = 373K

T1 = ?

Assumption:

-Steady- state condition

-One- dimensional conduction

-No uniform heat generation

-Constant properties

From Energy balance equation;

E°in - E°out = 0

Thus,

q"cond – q"conv – q"rad = 0

K[(T1 - T2)/L] - h(Ts-T_α) - εσ (Ts⁴ – Tsur⁴)

Where σ is Stephan-Boltzmann constant and has a value of 5.67 x 10^(-8)

Thus;

K[(T1 - T2)/L] - h(Ts-T_α) - εσ (Ts⁴ – Tsur⁴) = 1.2[(T1 - 373)/0.15] - 20(373 - 298] - 0.8x5.67x10^(-8)[373⁴ - 298⁴] = 0

This gives;

(8T1 - 2984) - (1500) - 520.31 = 0

8T1 = 2984 + 1500 + 520.31

8T1 = 5004.31

T1 = 5004.31/8

T1 = 625.54 K

7 0

3 years ago
