Answer:
the answers are
W = 1271.256 J
= 361.81 J
Explanation:
The mass of the trunk (m) = 46kg
angle between the ramp and the horizontal (θ) = 42°
The trunk is pulled at a displacement (d) up the ramp = 3m
The coefficient of kinetic friction between the trunk and the ramp = 0.36
The trunk is moving with a constant velocity therefore the net force on it is zero, therefore the force required to move the trunk must be equal to the summation of forces opposing the trunk
The two forces opposing the trunk are
- the gravitational force directed down the ramp and
- the frictional force between the ramp and the trunk
We have to calculate the machine's force which is equal to sum of the
= θ
μ× N
N = mgcosθ
μθ
F = mg (sinθ + μcosθ)
F = 46× 9.8 (sin42 + 0.36×cos42)
F= 450.8 (0.67 +0.27)
F = 450.8 × 0.94
F = 423.752N
to calculate the workdone on the trunk by the machine force
The workdone on the trunk is = W = F × dcosΘ
Θ = 0° because the trunk is directed parallel to the ramp
W =423.752× 3 cos 0
W = 423.752 ×3
W = 1271.256 J
(b) the increase in thermal energy of the trunk and the ramp
Friction converts mechanical energy into thermal energy, so multiplying the frictional force with the distance gives the thermal energy generated by the trunk
× d
= μθ ×d
= 0.36 ×46×9.8×cos42×3
= 361.81 J
Answer:
Explanation:
Electron information needed to solve the question:
Answer: They are in the same group because they have similar chemical properties, but they are in different periods because they have very different atomic numbers.
Explanation: On Edgenuity!!
I attached the full question.
We know that for a parallel-plate capacitor the surface charge density is given by the following formula:
Where V is the voltage between the plates and d is separation.
Voltage is by definition:
Voltage is analog to the mechanical work done by the force.
Above formula is correct only If the field is constant, and we can assume that it is since no function has been given.
The charge density would then be:
Please note that elecric permittivity of air is very close to elecric permittivity of vacum, it is common to use them <span>interchangeably</span>.
