An aggregate blend consists of 65% of aggregate A and 35% of aggregate B. The bulk specific gravities of aggregate A and B are 2

.45 and 3.25, respectively. What is the bulk specific gravity of the blend?
a) 2.45
b) 2.68
c) 2.73
d) 2.92

1 answer:

lozanna [386]3 years ago

8 0

Answer:

2.68

Explanation:

Percentage by Mass of each Aggregate :

Pa = 65% ; Pb = 35%;

Bulk Specific gravity of each aggregate :

Ga = 2.45 ; Gb = 3.25

Gsb = (Pa + Pb) / (Pa/Ga + Pb/Gb)

Gsb = (65 + 35) / (65/2.45 + 35/3.25)

Gsb = (65 + 35) / 37.299843

Gsb = 100 / 37.299843

Gsb = 2.68
